IGNTION SYSTEM KOKUSAN для Ktm 250 EXC - 2004 года выпуска
-
№АртикулНазвание
-
254739005144 FLYWHEEL KOKUSAN 2K-2 CPL. (USA)FLYWHEEL KOKUSAN 2K-2 CPL. (USA)
-
350339005200 FLYWHEEL KOKUSAN 2K-3 (EURO/AUS)FLYWHEEL KOKUSAN 2K-3 (EURO/AUS)
-
550339004100 STATOR KOKUSAN 2K-2 (USA)STATOR KOKUSAN 2K-2 (USA)
-
650339004200 STATOR KOKUSAN 2K-3 (EURO/AUS)STATOR KOKUSAN 2K-3 (EURO/AUS)
-
70015050163 HH COLLAR SCREW M 5X16 WS=8HH COLLAR SCREW M 5X16 WS=8
-
1054839131100 CDI UNITCDI UNIT
-
1250339006000 IGNI.COIL KOKU.3834IGNI.COIL KOKU.3834
-
1350311035000 CONDENSATOR 2200MF ADP-48CONDENSATOR 2200MF ADP-48
-
1454711034000 VOLTAGE REGULATOR KOKU. (EURO/AUS)VOLTAGE REGULATOR KOKU. (EURO/AUS)
-
1550311034000 VOLTAGE REGULA. 12V (USA)VOLTAGE REGULA. 12V (USA)
-
1654739093000 SPARK PLUG NGK BR7ESSPARK PLUG NGK BR7ES
-
1754531010000 SPARK PLUG CAP LB05EMH NGKSPARK PLUG CAP LB05EMH NGK
-
1950231012000 SEALING CUP FOR SPARK PLUGSEALING CUP FOR SPARK PLUG
-
200015060163 HH COLLAR SCREW M 6X16 WS=8HH COLLAR SCREW M 6X16 WS=8
-
210014060103 HH COLLAR SCREW M 6X10 WS=8HH COLLAR SCREW M 6X10 WS=8
-
220015060123 HH COLLAR SCREW M 6X12 WS=8HH COLLAR SCREW M 6X12 WS=8
