VALVE DRIVE для Ktm 250 EXC RFS - 2004 года выпуска

  • №
    Артикул
    Название
  • 1
    59836030000 INTAKE VALVE 28 MM
    INTAKE VALVE 28 MM
  • 2
    59836031000 EXHAUST VALVE 24 MM
    EXHAUST VALVE 24 MM
  • 3
    59036027000 VALVE-STEM SEALING
    VALVE-STEM SEALING
  • 6
    59836028144 VALVE SPR.CONICAL CPL.
    VALVE SPR.CONICAL CPL.
  • 9
    60036033000 VALVE COLLET MK6 02
    VALVE COLLET MK6 02
  • 10
    59036062000 ADJUSTMENT SCREW M6X0, 75
    ADJUSTMENT SCREW M6X0, 75
  • 11
    59036062100 NUT M6X0,75
    NUT M6X0,75
  • 13
    59036056000 ROCKER ARM SHAFT INTAKE 82MM
    ROCKER ARM SHAFT INTAKE 82MM
  • 14
    59036057000 ROCKER ARM SHAFT EXHAUST 94MM
    ROCKER ARM SHAFT EXHAUST 94MM
  • 15
    59036061095 END CAP ROCKER ARM SHAFT
    END CAP ROCKER ARM SHAFT
  • 16
    0770191016 O-RING 19,107X1,60 NBR 70
    O-RING 19,107X1,60 NBR 70
  • 17
    59036060010 SHIM ALU 5,2X10X2
    SHIM ALU 5,2X10X2
  • 18
    0912050083 AH SCREW DIN0912-M 5X 8
    AH SCREW DIN0912-M 5X 8
  • 19
    59036050000 DECOMPRESSION SHAFT CPL.
    DECOMPRESSION SHAFT CPL.
  • 20
    0770051016 O-RING 5,107(1,60 NBR 70
    O-RING 5,107(1,60 NBR 70
  • 22
    59036059000 DECOMPRESS/ON LEVER SPRING
    DECOMPRESS/ON LEVER SPRING
  • 23
    0471080000 CIRCLIP DIN0471- 8X0,8
    CIRCLIP DIN0471- 8X0,8
  • 30
    59836060044 ROCKER ARM INTAKE CPL.
    ROCKER ARM INTAKE CPL.
  • 31
    59836061044 ROCKER ARM EXHAUST CPL.
    ROCKER ARM EXHAUST CPL.
