FRAME - SIDE STAND для Ktm 50 Jr Adventure - 2001 года выпуска`
-
№АртикулНазвание
-
145003001400 FRAME PRO JUNIOR SILVERFRAME PRO JUNIOR SILVER
-
345003005100 ENGINE BRACKETENGINE BRACKET
-
50015080403 HH COLLAR SCREW M 8X40 WS=10HH COLLAR SCREW M 8X40 WS=10
-
70015080163 HH COLLAR SCREW M 8X16 WS=10HH COLLAR SCREW M 8X16 WS=10
-
80985080003 SELF LOCKING NUT DIN0985-M 8SELF LOCKING NUT DIN0985-M 8
-
1345003023000 SIDE STAND L=290MM SILVERSIDE STAND L=290MM SILVER
-
1551003021000 SIDESTAND SPRING LONGSIDESTAND SPRING LONG
-
160933080203 HH SCREW DIN0933-M 8X20HH SCREW DIN0933-M 8X20
-
1736003014000 LOCK WASHER 8MMLOCK WASHER 8MM
-
1850203053000 CHAIN ROLL D=30MMCHAIN ROLL D=30MM
-
190015080353 HH COLLAR SCREW M 8X35 WS=10HH COLLAR SCREW M 8X35 WS=10
-
200125080003 WASHER DIN0125-A 8,4WASHER DIN0125-A 8,4
-
2174003021000 BUSHING 8 X 12 X 6,5BUSHING 8 X 12 X 6,5
-
220625006087 GROOVED BALL BEAR. 608 2RS C3GROOVED BALL BEAR. 608 2RS C3
-
230015060123 HH COLLAR SCREW M 6X12 WS=8HH COLLAR SCREW M 6X12 WS=8
-
300125080003 WASHER DIN0125-A 8,4WASHER DIN0125-A 8,4
-
310094032253 PIN DIN0094-3,2X25 STEELPIN DIN0094-3,2X25 STEEL
-
3254603041000 FOOTREST SPRING L/S & R/SFOOTREST SPRING L/S & R/S
-
3354603044000 BOLT FOR FOOTREST 9,8 X 50BOLT FOR FOOTREST 9,8 X 50
-
355460304000090 FOOT REST L/S SILVERFOOT REST L/S SILVER
-
355460314000090 FOOT REST R/S SILVERFOOT REST R/S SILVER
