ENGINE CASE для Ktm 400 EXC Racing - 2001 года выпуска

  • №
    Артикул
    Название
  • 01
    59030000044 ENGINE CASE CPL.W.TR.BEAR.
    ENGINE CASE CPL.W.TR.BEAR.
  • 2
    51030026100 DOWEL 17 X14 X12
    DOWEL 17 X14 X12
  • 3
    49030090000 DOWEL 9,8 X 7 X 10
    DOWEL 9,8 X 7 X 10
  • 4
    59030090000 HANGER FOR VENT HOSE
    HANGER FOR VENT HOSE
  • 5
    0014060153 HH COLLAR SCREW M 6X15 WS=8
    HH COLLAR SCREW M 6X15 WS=8
  • 6
    58030021000 OILDRAIN PLUG W.MAGNET M12X1,5
    OILDRAIN PLUG W.MAGNET M12X1,5
  • 7
    58038022000 CU-SEAL RING DIN7603-12X18X1,5
    CU-SEAL RING DIN7603-12X18X1,5
  • 9
    0908120153 PLUG DIN0908-M12X1,5
    PLUG DIN0908-M12X1,5
  • 10
    50130027000 DOWEL 19 X15,1X12
    DOWEL 19 X15,1X12
  • 11
    58038023300 PRESSURE SPRING L=25MM D=1MM
    PRESSURE SPRING L=25MM D=1MM
  • 12
    58038028000 VALVE PISTON D=10MM
    VALVE PISTON D=10MM
  • 17
    59031050000 TUBE ENGINE BREATHER 0,71M
    TUBE ENGINE BREATHER 0,71M
  • 18
    59030022100 BLEEDER FLANGE M12X1,5 WS=13
    BLEEDER FLANGE M12X1,5 WS=13
  • 19
    58030080000 LOCATING SCREW M8
    LOCATING SCREW M8
  • 20
    58030081000 CU-SEAL RING 8 X 14 X 3
    CU-SEAL RING 8 X 14 X 3
  • 22
    59030019000 OIL LEVEL VIEWER G 1777 Y
    OIL LEVEL VIEWER G 1777 Y
  • 23
    59030020044 OIL DIPSTICK CPL. L=102MM
    OIL DIPSTICK CPL. L=102MM
  • 24
    0770191015 O-RING 19,00X3,00 NBR
    O-RING 19,00X3,00 NBR
  • 26
    0402040980 NEEDLE ROL.DIN5402 NRB 4X 9,8
    NEEDLE ROL.DIN5402 NRB 4X 9,8
  • 30
    0985050083 FLAT HEAD SCREW DIN7985-M 5X 8
    FLAT HEAD SCREW DIN7985-M 5X 8
  • 32
    59013068000 BRACKET BRAKE FLUID RESERVOIR
    BRACKET BRAKE FLUID RESERVOIR
