FRAME W/ SIDE STAND для Ktm 50 SX Pro Sr - 2000 года выпуска

  • №
    Артикул
    Название
  • 1
    45003001400 FRAME (SILVER)
    FRAME (SILVER)
  • 2
    45003005000 ENGINE BRACKET
    ENGINE BRACKET
  • 4
    45003005200 ENGINE BRACKET
    ENGINE BRACKET
  • 5
    0015080403 HH COLLAR SCREW M 8X40 WS=10
    HH COLLAR SCREW M 8X40 WS=10
  • 6
    0015080553 HH COLLAR SCREW M 8X55 WS=10
    HH COLLAR SCREW M 8X55 WS=10
  • 7
    0015080163 HH COLLAR SCREW M 8X16 WS=10
    HH COLLAR SCREW M 8X16 WS=10
  • 8
    0985080003 SELF LOCKING NUT DIN0985-M 8
    SELF LOCKING NUT DIN0985-M 8
  • 9
    45003040000 FOOT REST (LEFT)
    FOOT REST (LEFT)
  • 9
    45003041000 FOOT REST (RIGHT)
    FOOT REST (RIGHT)
  • 10
    45003042000 SPRING (LEFT)
    SPRING (LEFT)
  • 10
    45003043000 SPRING (RIGHT)
    SPRING (RIGHT)
  • 13
    45003023000 SIDE STAND L=290 MM
    SIDE STAND L=290 MM
  • 13
    45003023000 SIDE STAND L=290MM (SILVER)
    SIDE STAND L=290MM (SILVER)
  • 15
    51003021000 SIDESTAND SPRING LONG
    SIDESTAND SPRING LONG
  • 16
    0933080203 HH SCREW DIN0933-M 8X20
    HH SCREW DIN0933-M 8X20
  • 17
    36003014000 LOCK WASHER 8MM
    LOCK WASHER 8MM
  • 18
    50203053000 CHAIN ROLL D=30MM
    CHAIN ROLL D=30MM
  • 19
    0015080353 HH COLLAR SCREW M 8X35 WS=10
    HH COLLAR SCREW M 8X35 WS=10
  • 20
    0125080003 WASHER DIN0125-A 8,4
    WASHER DIN0125-A 8,4
  • 21
    74003021000 BUSHING 8 X 12 X 6,5
    BUSHING 8 X 12 X 6,5
  • 22
    0625006087 GROOVED BALL BEAR. 608 2RS C3
    GROOVED BALL BEAR. 608 2RS C3
  • 23
    0015060123 HH COLLAR SCREW M 6X12 WS=8
    HH COLLAR SCREW M 6X12 WS=8
  • 24
    54310086200 SELF LOCKING NUT M8 10.9
    SELF LOCKING NUT M8 10.9
  • 30
    0125080003 WASHER DIN0125-A 8,4
    WASHER DIN0125-A 8,4
  • 31
    0094032253 PIN DIN0094-3,2X25 STEEL
    PIN DIN0094-3,2X25 STEEL
  • 32
    54603041000 FOOTREST SPRING (LEFT AND RIGHT)
    FOOTREST SPRING (LEFT AND RIGHT)
  • 33
    54603044000 BOLT FOR FOOTREST 9,8 X 50
    BOLT FOR FOOTREST 9,8 X 50
  • 35
    5460304000090 FOOT REST (LEFT) (SILVER)
    FOOT REST (LEFT) (SILVER)
  • 35
    5460314000090 FOOT REST (RIGHT) (SILVER)
    FOOT REST (RIGHT) (SILVER)
