TRANSMISSION для Kawasaki NINJA ZX-10R ABS (ZX1000KDF) - 2013 года выпуска

  • №
    Артикул
    Название
  • 600
    600A0500 BALL-STEEL, 5/32
    BALL-STEEL, 5/32
  • 13127
    13127-0636 SHAFT-TRANSMISSION INPUT
    SHAFT-TRANSMISSION INPUT
  • 13128
    13128-0670 SHAFT-TRANSMISSION OUTPUT
    SHAFT-TRANSMISSION OUTPUT
  • 13144
    13144-0004 SPROCKET-OUTPUT, 17T, #525
    SPROCKET-OUTPUT, 17T, #525
  • 13262
    13262-0615 GEAR, OUTPUT LOW, 39T
    GEAR, OUTPUT LOW, 39T
  • 13262A
    13262-0803 GEAR, OUTPUT 3RD, 33T
    GEAR, OUTPUT 3RD, 33T
  • 13262B
    13262-0804 GEAR, OUTPUT 4TH, 33T
    GEAR, OUTPUT 4TH, 33T
  • 13262C
    13262-0805 GEAR, OUTPUT 5TH, 26T
    GEAR, OUTPUT 5TH, 26T
  • 13262E
    13262-0856 GEAR, INPUT 2ND, 19T
    GEAR, INPUT 2ND, 19T
  • 13262F
    13262-0869 GEAR, INPUT TOP, 23T
    GEAR, INPUT TOP, 23T
  • 13262H
    13262-0881 GEAR, INPUT 5TH, 18T
    GEAR, INPUT 5TH, 18T
  • 13262I
    13262-0891 GEAR, INPUT 3RD & 4TH, 19T & 21T
    GEAR, INPUT 3RD & 4TH, 19T & 21T
  • 13262J
    13262-0916 GEAR, OUTPUT 2ND, 39T
    GEAR, OUTPUT 2ND, 39T
  • 13262K
    13262-0917 GEAR, OUTPUT TOP, 31T
    GEAR, OUTPUT TOP, 31T
  • 92015
    92015-1963 NUT, 20MM
    NUT, 20MM
  • 92033
    92033-1037 RING-SNAP, 25.9X30.6X1.2
    RING-SNAP, 25.9X30.6X1.2
  • 92033A
    92033-1249 RING-SNAP, T=1.5
    RING-SNAP, T=1.5
  • 92045
    92045-0047 BEARING-BALL, 830045-5SH2
    BEARING-BALL, 830045-5SH2
  • 92045A
    92045-0048 BEARING-BALL, DG2152RDDSH2
    BEARING-BALL, DG2152RDDSH2
  • 92045B
    92045-0156 BEARING-BALL, 63/22LU
    BEARING-BALL, 63/22LU
  • 92045C
    92045-1189 BEARING-BALL, 63/28
    BEARING-BALL, 63/28
  • 92055
    92055-1293 RING-O, 21.5X1.5
    RING-O, 21.5X1.5
  • 92139
    92139-0036 BUSHING, GEAR, 6TH IN
    BUSHING, GEAR, 6TH IN
  • 92139A
    92139-0038 BUSHING, GEAR, LOW OUT
    BUSHING, GEAR, LOW OUT
  • 92139B
    92139-0309 BUSHING, 25.0X31.0X9.4
    BUSHING, 25.0X31.0X9.4
  • 92139C
    92139-0324 BUSHING, 28.1X31.0X13.5
    BUSHING, 28.1X31.0X13.5
  • 92139D
    92139-0734 BUSHING, 28.1X31.0X11.5
    BUSHING, 28.1X31.0X11.5
  • 92152
    92152-0885 COLLAR
    COLLAR
  • 92200
    92200-0050 WASHER, 28.3X34.0X1.6
    WASHER, 28.3X34.0X1.6
  • 92200A
    92200-0138 WASHER, 22.1X32.0X1.4
    WASHER, 22.1X32.0X1.4
  • 92200B
    92200-1065 WASHER
    WASHER
  • 92200C
    92200-1522 WASHER, 25.8X40.5X1.5
    WASHER, 25.8X40.5X1.5
  • 92200D
    92200-1523 WASHER, 25.2X37.0X1.0
    WASHER, 25.2X37.0X1.0
