TRANSMISSION для Kawasaki ELIMINATOR 125 (BN125A7F) - 2007 года выпуска

  • №
    Артикул
    Название
  • 120
    120Q0608 BOLT-SOCKET, 6X8
    BOLT-SOCKET, 6X8
  • 13127
    13127-0001 SHAFT-TRANSMISSION INPUT
    SHAFT-TRANSMISSION INPUT
  • 13128
    13128-0001 SHAFT-TRANSMISSION OUTPUT
    SHAFT-TRANSMISSION OUTPUT
  • 13129
    13129-1555 GEAR, INPUT 2ND, 17T
    GEAR, INPUT 2ND, 17T
  • 13129A
    13129-1621 GEAR, INPUT 5TH, 21T
    GEAR, INPUT 5TH, 21T
  • 13139
    13139-1094 SHIFTER
    SHIFTER
  • 13144
    13144-1310 SPROCKET-OUTPUT, 15T
    SPROCKET-OUTPUT, 15T
  • 13260
    13260-1019 GEAR, OUTPUT LOW, 27T
    GEAR, OUTPUT LOW, 27T
  • 13260A
    13260-1693 GEAR, OUTPUT 5TH, 20T
    GEAR, OUTPUT 5TH, 20T
  • 13260B
    13260-1704 GEAR, OUTPUT 2ND, 29T
    GEAR, OUTPUT 2ND, 29T
  • 13260C
    13260-1705 GEAR, OUTPUT 3RD, 26T
    GEAR, OUTPUT 3RD, 26T
  • 13260D
    13260-1739 GEAR, INPUT 3RD & 4TH, 20T/22T
    GEAR, INPUT 3RD & 4TH, 20T/22T
  • 13260E
    13260-1740 GEAR, OUTPUT 4TH, 24T
    GEAR, OUTPUT 4TH, 24T
  • 13271
    13271-1052 PLATE, SPROCKET
    PLATE, SPROCKET
  • 92022
    92022-1033 WASHER, TOOTHED, 20.3X24X0.5
    WASHER, TOOTHED, 20.3X24X0.5
  • 92022A
    92022-252 WASHER, 20.5X25.5X0.5
    WASHER, 20.5X25.5X0.5
  • 92033
    92033-1260 RING-SNAP
    RING-SNAP
  • 92033A
    92033-1313 RING-SNAP
    RING-SNAP
  • 92055
    92055-022 RING-O, 17.5X1.5
    RING-O, 17.5X1.5
  • 92143
    92143-1868 COLLAR, 20X24.6X10.5
    COLLAR, 20X24.6X10.5
  • 92143A
    92143-1869 COLLAR, SPROCKET
    COLLAR, SPROCKET
