CHASSIS ELECTRICAL EQUIPMENT для Kawasaki Vulcan 1500 Classic - 2001 года выпуска
-
№АртикулНазвание
-
130130J0630 BOLT, FLANGED, 6X30 (BLACK)BOLT, FLANGED, 6X30 (BLACK)
-
130A130V0610 BOLT, FLANGED, 6X10BOLT, FLANGED, 6X10
-
2106121061-1003 RECTIFIERRECTIFIER
-
2600626006-1067 FUSE, 30A, GFUSE, 30A, G
-
26006A26006-1068 FUSE, 10A, RFUSE, 10A, R
-
26011B26011-1770 WIRE, LEAD, BATTERY (+)WIRE, LEAD, BATTERY (+)
-
26011C26011-1771 WIRE, LEAD, BATTERY (-)WIRE, LEAD, BATTERY (-)
-
2601226012-1368 BATTERY, MF, FTH16, BS, 12V 14AHBATTERY, MF, FTH16, BS, 12V 14AH
-
2602126021-1089 JUNCTION BOXJUNCTION BOX
-
2603026030-1450 HARNESS, SUBHARNESS, SUB
-
26030B26030-1797 HARNESS, MAINHARNESS, MAIN
-
27002A27002-1111 RELAY, ASSY., SIGNAL LAMPRELAY, ASSY., SIGNAL LAMP
-
2700327003-1406 HORNHORN
-
4901649016-1177 COVER, SEAL, FUSECOVER, SEAL, FUSE
-
9203792037-1539 CLAMP, L=45CLAMP, L=45
-
92037A92037-1780 CLAMPCLAMP
-
9207292072-1195 BAND, L=202BAND, L=202
-
9207592075-1688 DAMPER, JUNCTION BOXDAMPER, JUNCTION BOX
-
9217092170-1699 CLAMP, IGNITION SWITCHCLAMP, IGNITION SWITCH
-
92170A92170-1700 CLAMP, REAR BRAKE SWITCHCLAMP, REAR BRAKE SWITCH
