FRAME FITTING(S) для Kawasaki KX250 (KX250R7F) - 2007 года выпуска`
-
№АртикулНазвание
-
132132L0610 BOLT-FLANGED-SMALL,6X10BOLT-FLANGED-SMALL,6X10
-
410410B1000 WASHER-PLAIN-SMALL,10MMWASHER-PLAIN-SMALL,10MM
-
1105311053-1629 BRACKET,IGNITERBRACKET,IGNITER
-
3219032190-0092 BRACKET-ENGINEBRACKET-ENGINE
-
9201592015-1432 NUT,8MMNUT,8MM
-
9203792037-1290 CLAMP,SPEED,L=43CLAMP,SPEED,L=43
-
9204592045-1009 BEARING-BALL,608LLU/2ABEARING-BALL,608LLU/2A
-
9207292072-1293 BAND,L=140BAND,L=140
-
9212292122-0007 ROLLER,CHAIN GUIDEROLLER,CHAIN GUIDE
-
9215092150-1125 BOLT,FLANGED,10X50BOLT,FLANGED,10X50
-
92150A92150-1214 BOLT,FLANGED,8X50BOLT,FLANGED,8X50
-
9215192151-1377 BOLT,FLANGED,8X52BOLT,FLANGED,8X52
-
9215292152-0211 COLLAR,8.5X12.5X15.5COLLAR,8.5X12.5X15.5
-
9215392153-0503 BOLT,6X12BOLT,6X12
-
92153A92153-0613 BOLT,FLANGED,10X95BOLT,FLANGED,10X95
-
92153B92153-0614 BOLT,FLANGED,10X105BOLT,FLANGED,10X105
-
92153C92153-0751 BOLT,FLANGED,8X45BOLT,FLANGED,8X45
-
9217092170-1925 CLAMPCLAMP
-
9217192171-0081 CLAMP,DIA=20CLAMP,DIA=20
-
92171A92171-1279 CLAMPCLAMP
-
92171B92171-1424 CLAMP,DIA=15CLAMP,DIA=15
-
9221092210-1080 NUT,LOCK,FLANGED,10MMNUT,LOCK,FLANGED,10MM
