FRAME FITTINGS для Kawasaki Prairie 400 (KVF400-D4) - 2002 года выпуска

  • №
    Артикул
    Название
  • 130
    130J0814 BOLT-FLANGED, 8X14
    BOLT-FLANGED, 8X14
  • 11049
    11049-1738 BRACKET
    BRACKET
  • 32029
    32029-1970 BRACKET-ENGINE, REAR (UPPER) (LEFT)
    BRACKET-ENGINE, REAR (UPPER) (LEFT)
  • 32029A
    32029-1971 BRACKET-ENGINE, REAR (UPPER) (RIGHT)
    BRACKET-ENGINE, REAR (UPPER) (RIGHT)
  • 32069
    32069-1547 BRACKET-MUFFLER
    BRACKET-MUFFLER
  • 32190
    32190-1078 BRACKET-ENGINE, HEAD
    BRACKET-ENGINE, HEAD
  • 32190A
    32190-1096 BRACKET-ENGINE, FRONT (LOWER)
    BRACKET-ENGINE, FRONT (LOWER)
  • 32190B
    32190-1097 BRACKET-ENGINE, REAR (LOWER)
    BRACKET-ENGINE, REAR (LOWER)
  • 92001
    92001-1600 BOLT, FLANGED, 10X70
    BOLT, FLANGED, 10X70
  • 92001A
    92001-1622 BOLT, FLANGED, 10X225 (BLACK)
    BOLT, FLANGED, 10X225 (BLACK)
  • 92002
    92002-1531 BOLT, FLANGED, 10X230
    BOLT, FLANGED, 10X230
  • 92002A
    92002-1645 BOLT, FLANGED, 8X16
    BOLT, FLANGED, 8X16
  • 92009
    92009-1166 SCREW, TAPPING, 6X16
    SCREW, TAPPING, 6X16
  • 92015
    92015-1727 NUT, FLANGED, 10MM
    NUT, FLANGED, 10MM
  • 92027
    92027-275 COLLAR, L=54
    COLLAR, L=54
  • 92150
    92150-1493 BOLT, FLANGED, 10X173.5
    BOLT, FLANGED, 10X173.5
  • 92150A
    92150-1731 BOLT, FLANGED, 10X100
    BOLT, FLANGED, 10X100
  • 92151
    92151-1137 BOLT, FLANGED, 10X16
    BOLT, FLANGED, 10X16
  • 92160
    92160-1692 DAMPER, ENGINE MOUNT
    DAMPER, ENGINE MOUNT
  • 92160A
    92160-1759 DAMPER, ENGINE MOUNT
    DAMPER, ENGINE MOUNT
  • 92160B
    92160-1772 DAMPER
    DAMPER
