08- Drive System, Rear _13C1511a для BRP Maverick MAX 1000_XDS-DPS - 2015
-
№АртикулНазвание
-
3230602546 Hex. Flanged Screw M10 X 125Hex. Flanged Screw M10 X 125
-
4230629087 Hex. Flanged Screw M12 X 190Hex. Flanged Screw M12 X 190
-
5250100161 Castle Nut M20Castle Nut M20
-
6233201436 Flanged Elastic Nut M10Flanged Elastic Nut M10
-
7233221416 Elastic Flange Nut M12Elastic Flange Nut M12
-
8250000359 Hex Flanged Screw M12 x 16Hex Flanged Screw M12 x 16
-
9250000435 Hex. Flanged Screw M6 X 25Hex. Flanged Screw M6 X 25
-
9a293450317 InsertInsert
-
10250000615 Hex Flanged Screwv M10 X 16Hex Flanged Screwv M10 X 16
-
11250100100 Black Wheel Nut M10 X 1.25Black Wheel Nut M10 X 1.25
-
12250200014 Flat Washer M10Flat Washer M10
-
13250200148 Spring WasherSpring Washer
-
14250200102 Flat Washer M12Flat Washer M12
-
15250300051 Wheel StudWheel Stud
-
16250400036 Cotter PinCotter Pin
-
17293000110 Valve CapValve Cap
-
18293350040 Cone BearingCone Bearing
-
19293370019 CirclipCirclip
-
23414115200 Tie-Rap 180 mmTie-Rap 180 mm
-
30715900278 Universal JointUniversal Joint
-
33715900295 Grease FittingGrease Fitting
-
34705400036 Wear RingWear Ring
-
35705400928 Wheel CapWheel Cap
-
36705400193 Rim Valve With CapRim Valve With Cap
-
37705401586 Manta Green- Painted Reinforcement DiskManta Green- Painted Reinforcement Disk
-
43705501123 ProtectorProtector
-
47705502236 CV JointCV Joint
-
48715900241 Oetiker Clamp, 82.1 mmOetiker Clamp, 82.1 mm
-
49715900242 Oetiker Clamp, 27.3 mmOetiker Clamp, 27.3 mm
-
53a715900118 Rubber BootRubber Boot
-
53b715900272 JointJoint
-
53c715900271 JointJoint
-
53d715900106 Spline YokeSpline Yoke
-
59705501730 LH Rear KnuckleLH Rear Knuckle
-
59705501731 RH Rear KnuckleRH Rear Knuckle
-
69705502144 Rear Tire. Model-North America, InternationalRear Tire. Model-North America, International
-
69705501434 Rear Tire. Model- EuropeRear Tire. Model- Europe
-
70705501841 Heat DissipatorHeat Dissipator
-
72705501864 Boot KitBoot Kit
-
77705501865 Plunging JointPlunging Joint
-
78705502235 Half Shaft Ass'yHalf Shaft Ass'y
-
78a705501781 CirclipCirclip
-
81703500877 Drive Axle Ass'yDrive Axle Ass'y
-
83705502146 Black Rim. Model-North America, InternationalBlack Rim. Model-North America, International
-
83705501853 Black Rim. Model- EuropeBlack Rim. Model- Europe
-
87415080200 Hose, PolyurethaneHose, Polyurethane
-
94705502223 Wheel HubWheel Hub
