07- Drive System, Front _12C1510a для BRP Maverick 1000_XDS-DPS - 2015
-
№АртикулНазвание
-
5207582044 Hex. Flanged Screw M8 X 20, Scotch GripHex. Flanged Screw M8 X 20, Scotch Grip
-
7230603046 Flanged Hex. Screw, M10 X 130Flanged Hex. Screw, M10 X 130
-
8250100047 Hex. Castellated Nut M18Hex. Castellated Nut M18
-
10233201436 Flanged Elastic Nut M10Flanged Elastic Nut M10
-
11234201474 Conical Spring Washer 10 mmConical Spring Washer 10 mm
-
12250000435 Hex. Flanged Screw M6 X 25Hex. Flanged Screw M6 X 25
-
12a293450317 InsertInsert
-
13250000615 Hex Flanged Screwv M10 X 16Hex Flanged Screwv M10 X 16
-
14250100100 Black Wheel Nut M10 X 1.25Black Wheel Nut M10 X 1.25
-
15250200014 Flat Washer M10Flat Washer M10
-
16250200049 Spring WasherSpring Washer
-
17250300051 Wheel StudWheel Stud
-
18250400036 Cotter PinCotter Pin
-
19293000110 Valve CapValve Cap
-
20293250246 O-RingO-Ring
-
21293350040 Cone BearingCone Bearing
-
22293370019 CirclipCirclip
-
29414115200 Tie-Rap 180 mmTie-Rap 180 mm
-
32705400036 Wear RingWear Ring
-
33705400780 Wear SleeveWear Sleeve
-
34705400928 Wheel CapWheel Cap
-
35705400193 Rim Valve With CapRim Valve With Cap
-
36705401196 Drive Axle Ass'yDrive Axle Ass'y
-
37715900116 Fixed Yoke JointFixed Yoke Joint
-
39715900231 Yoke Joint. Cover 715900483Yoke Joint. Cover 715900483
-
41703500813 Grease FittingGrease Fitting
-
42703500814 Unit Pack KitUnit Pack Kit
-
42a715900183 U-JointU-Joint
-
45705401346 Boot Kit, Differential SideBoot Kit, Differential Side
-
46705401345 Boot Kit, Wheel SideBoot Kit, Wheel Side
-
47705401344 CV JointCV Joint
-
49715900284 Oetiker Clamp, LargeOetiker Clamp, Large
-
50715900261 Oetiker Clamp, SmallOetiker Clamp, Small
-
51715900282 Oetiker Clamp, LargeOetiker Clamp, Large
-
52715900283 Oetiker Clamp, SmallOetiker Clamp, Small
-
54705401348 RH Plunging JointRH Plunging Joint
-
54705401350 LH Plunging JointLH Plunging Joint
-
54a705401349 Circlip JointCirclip Joint
-
55705401236 RH Constant-Speed Universal JointRH Constant-Speed Universal Joint
-
55705401235 LH Constant-Speed Universal JointLH Constant-Speed Universal Joint
-
61715900117 Snap RingSnap Ring
-
74705401548 LH Front KnuckleLH Front Knuckle
-
74705401549 RH Front KnuckleRH Front Knuckle
-
76705401594 Black Front Rim. Model-North America, InternationalBlack Front Rim. Model-North America, International
-
76705401417 Black Front Rim. Model-EuropeBlack Front Rim. Model-Europe
-
78705401586 Manta Green- Painted Reinforcement DiskManta Green- Painted Reinforcement Disk
-
99705500504 Fill Level PlugFill Level Plug
-
100705500506 Copper WasherCopper Washer
-
102705401046 Front Tire. Model-EuropeFront Tire. Model-Europe
-
102705401592 Front Tire. Model-North America, InternationalFront Tire. Model-North America, International
-
104705501900 Wheel HubWheel Hub
-
105415080200 Hose, PolyurethaneHose, Polyurethane
