01- Cooling System _10M1528 для BRP Ski-Doo Tundra Sport 550F XU-137 - 2015
-
№АртикулНазвание
-
3250000079 Panel Nut M5 X 0.8Panel Nut M5 X 0.8
-
4250000130 Torx Screw M5 X 20Torx Screw M5 X 20
-
5250000377 Plastite Screw Type K-40 M4 X 16Plastite Screw Type K-40 M4 X 16
-
6391301600 WasherWasher
-
15509000540 Outlet Duct Ass.Outlet Duct Ass.
-
18509000543 Air Chamber Ass'yAir Chamber Ass'y
-
24509000840 Inlet DuctInlet Duct
