02- Air Intake System _35M1515 для BRP Ski-Doo Summit Sport 600 XP146 - 2015
-
№АртикулНазвание
-
1205444086 Socket Head Screw M4 X 40Socket Head Screw M4 X 40
-
2224060201 Flat WasherFlat Washer
-
3232541414 Elastic Stop Nut M4Elastic Stop Nut M4
-
4293300115 O-RingO-Ring
-
5415129376 Filter CoverFilter Cover
-
6415129377 Foam FilterFoam Filter
-
7508000346 Gemi ClampGemi Clamp
-
10508000500 Plate AdapterPlate Adapter
-
11508000501 Air Intake AdapterAir Intake Adapter
-
12508000532 Velcro StripVelcro Strip
-
13516005280 Caution Decal, Hot PartsCaution Decal, Hot Parts
-
17508000744 StopperStopper
-
22508000567 BootBoot
-
24508000572 BumperBumper
-
25508000574 GrommetGrommet
-
26508000576 SpringSpring
-
29508000656 Secondary Chamber Ass'ySecondary Chamber Ass'y
-
30508000626 Air FilterAir Filter
-
32508000661 FluteFlute
-
34508000674 Insulated FoamInsulated Foam
-
35508000680 Primary Chamber Ass'y. Includes 35 To 35aPrimary Chamber Ass'y. Includes 35 To 35a
-
35a516005876 Notice Decal, Air Intake SilencerNotice Decal, Air Intake Silencer
-
40514052924 Norma ClampNorma Clamp
