01- Cooling System для BRP Ski-Doo EXPEDITION SPORT 550F XP - 2013

  • №
    Артикул
    Название
  • 3
    250000079 Panel Nut M5 X 0.8
    Panel Nut M5 X 0.8
  • 4
    250000130 Torx Screw M5 X 20
    Torx Screw M5 X 20
  • 5
    250000377 Plastite Screw Type K-40 M4 X 16
    Plastite Screw Type K-40 M4 X 16
  • 6
    391301600 Washer
    Washer
  • 9
    509000451 Air Chamber
    Air Chamber
  • 10
    509000452 Outlet Duct
    Outlet Duct
  • 21
    509000574 Air Inlet Foam
    Air Inlet Foam
  • 22
    509000611 Outlet Air Deflector. White Models Except TUNDRA
    Outlet Air Deflector. White Models Except TUNDRA
  • 24
    509000840 Inlet Duct
    Inlet Duct
  • 29
    732610072 Push Nut
    Push Nut
