09- Frame для BRP Ski-Doo GSX 800 HO - 2004

  • №
    Артикул
    Название
  • 1
    415128812 Frame. INCLUDES ITEMS 1 TO 33
    Frame. INCLUDES ITEMS 1 TO 33
  • 2
    518323346 Engine Support (Black)
    Engine Support (Black)
  • 3
    518324162 RH Toe Hold Support
    RH Toe Hold Support
  • 4
    518324163 LH Toe Hold Support
    LH Toe Hold Support
  • 5
    518323507 Outer Reinforcement
    Outer Reinforcement
  • 6
    518323572 RH Slide Bracket
    RH Slide Bracket
  • 7
    518323573 LH Slide Bracket
    LH Slide Bracket
  • 8
    518323835 Rear Cap
    Rear Cap
  • 9
    518323241 Inner Reinforcement (Black)
    Inner Reinforcement (Black)
  • 10
    518323805 RH Footrest Reinforcement
    RH Footrest Reinforcement
  • 11
    518323765 LH Footrest Reinforcement
    LH Footrest Reinforcement
  • 12
    518324169 Plate
    Plate
  • 13
    518324242 Rear Radiator. INCLUDES ITEMS 13 TO 14 / GSX SS 500 / GSX 800 HO
    Rear Radiator. INCLUDES ITEMS 13 TO 14 / GSX SS 500 / GSX 800 HO
  • 518323646 Front Radiator. INCLUDES ITEMS 13 TO 14 / GSX 600 HO
    Front Radiator. INCLUDES ITEMS 13 TO 14 / GSX 600 HO
  • 14
    415012300 Radiator Protector
    Radiator Protector
  • 15
    293200003 Seal
    Seal
  • 16
    518323753 RH Reinforcement (Black)
    RH Reinforcement (Black)
  • 17
    518323754 LH Reinforcement (Black)
    LH Reinforcement (Black)
  • 18
    390909200 Rivet Avex
    Rivet Avex
  • 19
    390909100 Rivet Avex
    Rivet Avex
  • 20
    390402200 Rivet 3/16''
    Rivet 3/16''
  • 21
    390402400 Pop Rivet 3/16''
    Pop Rivet 3/16''
  • 22
    390910300 Rivet Henrob
    Rivet Henrob
  • 23
    518323551 RH Roller
    RH Roller
  • 24
    518323552 LH Roller
    LH Roller
  • 25
    205982086 Socket Head Screw M8 X 20, Scotch Grip
    Socket Head Screw M8 X 20, Scotch Grip
  • 26
    234082410 Flat Washer 8 mm
    Flat Washer 8 mm
  • 27
    293150096 Rivet
    Rivet
  • 28
    518323919 RH Frame Reinforcement
    RH Frame Reinforcement
  • 29
    518323920 LH Frame Reinforcement
    LH Frame Reinforcement
  • 30
    518322791 Tank Bracket
    Tank Bracket
  • 31
    518323336 RH Frame Reinforcement (Black)
    RH Frame Reinforcement (Black)
  • 32
    518323337 LH Frame Reinforcement (Black)
    LH Frame Reinforcement (Black)
  • 33
    518323328 RH Tunnel Stiffener
    RH Tunnel Stiffener
