09- Front Cover _26S1505 для BRP RXT-X aS 260 & RS. 2015 - 2015

  • №
    Артикул
    Название
  • 1
    232561200 Elastic Stop Nut M6, Brass
    Elastic Stop Nut M6, Brass
  • 2
    234041600 Flat Washer 4 mm, Stainless
    Flat Washer 4 mm, Stainless
  • 3
    241141360 Hex. Flanged Screw K40 X 13
    Hex. Flanged Screw K40 X 13
  • 4
    269500453 Mirror Spring
    Mirror Spring
  • 5
    269501664 Shock Absorber
    Shock Absorber
  • 6
    269501771 Black RH Mirror Housing. Package-X, XRS
    Black RH Mirror Housing. Package-X, XRS
  • 6
    269501772 Black LH Mirror Housing. Package-X, XRS
    Black LH Mirror Housing. Package-X, XRS
  • 7
    269501717 Shock End Piece
    Shock End Piece
  • 9
    269502089 Black Front Cosmetic
    Black Front Cosmetic
  • 11
    269501964 Left Latch
    Left Latch
  • 12
    269501965 Right Latch
    Right Latch
  • 14
    269502078 Yellow Upper Front Deflector
    Yellow Upper Front Deflector
  • 15
    269502076 Silver Hood Assembly
    Silver Hood Assembly
  • 16
    291001203 Spacer
    Spacer
  • 19
    293750001 Tie-Rap 94 mm
    Tie-Rap 94 mm
  • 20
    293830135 Rubber Bumper
    Rubber Bumper
  • 21
    269501920 RH Mirror Ass'y
    RH Mirror Ass'y
  • 22
    269501918 LH Mirror Ass'y
    LH Mirror Ass'y
  • 23
    241141660 Flanged Hex. Screw K40 X 16
    Flanged Hex. Screw K40 X 16
