09- Seat для BRP RXT 215 - 2010
-
№АртикулНазвание
-
1269001700 Seat Ass'y. Includes 1 to 13Seat Ass'y. Includes 1 to 13
-
2269501166 Nut Housing Ass'yNut Housing Ass'y
-
3296000299 Lateral Arm. Includes 3 to 4. Includes Spacer 269001588 (2x)Lateral Arm. Includes 3 to 4. Includes Spacer 269001588 (2x)
-
5234062600 Flat Washer M6, StainlessFlat Washer M6, Stainless
-
6205462060 Socket Screw M6 X 20Socket Screw M6 X 20
-
7293200124 SealSeal
-
8269700116 Latch Ass'yLatch Ass'y
-
9293150151 Rivet 1/4''Rivet 1/4''
-
10b293150143 Pop Rivet 1/8Pop Rivet 1/8
-
11269001580 Seat StrapSeat Strap
-
12293150067 RivetRivet
-
13293720067 GrommetGrommet
-
14231085060 Hex. Screw M8 X 150Hex. Screw M8 X 150
-
15232581200 Hex. Elastic Nut M8, BrassHex. Elastic Nut M8, Brass
-
16269501699 Center ArmCenter Arm
-
17269001684 ShockShock
-
18269001589 SpacerSpacer
-
22207265560 Hex. Screw M6 X 55, Scotch GripHex. Screw M6 X 55, Scotch Grip
-
23234062600 Flat Washer M6, StainlessFlat Washer M6, Stainless
-
24250100083 Expansion Nut M6 X 1Expansion Nut M6 X 1
-
25234062600 Flat Washer M6, StainlessFlat Washer M6, Stainless
-
26269002077 End FittingEnd Fitting
-
27205562560 Socket Head Screw M6 x 25 (Scotch Grip)Socket Head Screw M6 x 25 (Scotch Grip)
