02- Oil System для BRP GTI LE RFI - 2004
-
№АртикулНазвание
-
1275000238 Oil TankOil Tank
-
2413802900 Injection Oil (12 X 1 Liter)Injection Oil (12 X 1 Liter)
-
2413803000 Injection Oil (3 X 4 Liters)Injection Oil (3 X 4 Liters)
-
2413803200 Injection Oil (205 Liters)Injection Oil (205 Liters)
-
3275000188 Filler HoseFiller Hose
-
4293650035 Tridon ClampTridon Clamp
-
5275000242 Filler NeckFiller Neck
-
6293250132 GasketGasket
-
7211100013 Nut-Neck Oil FillerNut-Neck Oil Filler
-
8275000186 Oil CapOil Cap
-
9275000199 Oil Tank CapOil Tank Cap
-
10293250025 O-RingO-Ring
-
11275500015 Oil Cap ChainOil Cap Chain
-
12390407900 Pop Rivet 1/8''Pop Rivet 1/8''
-
13234032600 Flat Washer 3 mmFlat Washer 3 mm
-
14278001401 Oil Lever Sensor Ass'Y. Includes 14 To 18Oil Lever Sensor Ass'Y. Includes 14 To 18
-
15278000218 Wire SealWire Seal
-
16278000222 Male TerminalMale Terminal
-
17278000217 Female Connector (2 Circuits)Female Connector (2 Circuits)
-
18293720008 GrommetGrommet
-
19275500549 Hose 1/4''Hose 1/4''
-
20293750002 Tie-Rap 130 mmTie-Rap 130 mm
-
21275000008 Hose 12 mm (Meter)Hose 12 mm (Meter)
-
22293650084 Norma ClampNorma Clamp
-
23275500398 Check ValveCheck Valve
-
24293720008 GrommetGrommet
-
25293710051 Fitting Elbow 90°Fitting Elbow 90°
-
26275000007 Hose 8 mmHose 8 mm
-
27293750001 Tie-Rap 94 mmTie-Rap 94 mm
-
28275000051 Oil FilterOil Filter
-
29275000007 Hose 8 mmHose 8 mm
-
30293750001 Tie-Rap 94 mmTie-Rap 94 mm
-
31293650042 Oetiker ClampOetiker Clamp
-
32275000008 Hose 12 mm (Meter)Hose 12 mm (Meter)
-
33293650084 Norma ClampNorma Clamp
