01- Oil Separator для BRP GTX 4-TEC, Supercharged - 2003
-
№АртикулНазвание
-
1420811840 Oil pump housingOil pump housing
-
2420837542 Pump shaft ass'yPump shaft ass'y
-
3420956675 Oil pump outer rotor 16 mmOil pump outer rotor 16 mm
-
4420811850 Oil pump coverOil pump cover
-
5420641048 Torx flanged screw M6 x 16Torx flanged screw M6 x 16
-
6420950970 GasketGasket
-
7420641238 Torx flanged screw M6 x 25Torx flanged screw M6 x 25
-
8420811892 Oil sieve coverOil sieve cover
-
9420630240 Seal ringSeal ring
-
10420950850 GasketGasket
-
11420256570 Oil sieveOil sieve
-
12420641228 Torx flanged screw M6 x 85Torx flanged screw M6 x 85
-
13420641238 Torx flanged screw M6 x 25Torx flanged screw M6 x 25
-
14420641238 Torx flanged screw M6 x 25Torx flanged screw M6 x 25
-
15420630231 GasketGasket
-
16420956761 Oil separator housingOil separator housing
-
17420256880 Oil pressure switchOil pressure switch
-
18420811962 Oil separator coverOil separator cover
-
19420956660 Shut off solenoidShut off solenoid
-
20420630540 GasketGasket
-
21420939250 Compression springCompression spring
-
22420856055 Valve discValve disc
-
23420845620 Retaining ringRetaining ring
-
24420641048 Torx flanged screw M6 x 16Torx flanged screw M6 x 16
-
25420630220 GasketGasket
-
26420641238 Torx flanged screw M6 x 25Torx flanged screw M6 x 25
-
27420956923 Plug coverPlug cover
-
28420660620 Retaining bandRetaining band
-
29420660090 Rubber bracketRubber bracket
-
30420847970 SpacerSpacer
-
31420827968 Flat washer M6Flat washer M6
-
32420641258 Torx flanged screw M6 x 35Torx flanged screw M6 x 35
-
33420851610 Front transport bracketFront transport bracket
-
34420641048 Torx flanged screw M6 x 16Torx flanged screw M6 x 16
-
35420956970 Formed hoseFormed hose
-
36420851673 Gear clampGear clamp
-
37420851663 Gear clampGear clamp
-
38420641323 Plug screw M10Plug screw M10
-
39293800060 Loctite 243, 10 mlLoctite 243, 10 ml
-
40293600039 Engine oil 4 strokes, 5W40, 12 x 1 literEngine oil 4 strokes, 5W40, 12 x 1 liter
