09- Body - Front Section - Pure Magnesium для BRP 003 - Outlander T 6X6 - 1000 EFI - T Regulation - 2020

  • №
    Артикул
    Название
  • 30
    233261434 Flanged Elastic Nut M6
    Flanged Elastic Nut M6
  • 35
    233201434 Hex. Flanged Elastic Nut M10
    Hex. Flanged Elastic Nut M10
  • 40
    705006812 Cargo Rack Center Support
    Cargo Rack Center Support
  • 50
    207682044 Hex. Flanged Screw M8 X 20
    Hex. Flanged Screw M8 X 20
  • 55
    207582544 Hex. Flanged Screw M8 X 25, Scotch Grip
    Hex. Flanged Screw M8 X 25, Scotch Grip
  • 60
    233281434 Hex. Flanged Elastic Nut M8
    Hex. Flanged Elastic Nut M8
  • 150
    705006134 LH Air Deflector
    LH Air Deflector
  • 160
    705006135 RH Air Deflector
    RH Air Deflector
  • 170
    715006101 Console Support Ass'y
    Console Support Ass'y
  • 180
    293830005 Rubber Bumper
    Rubber Bumper
  • 200
    715004087 Indicator
    Indicator
  • 220
    207563034 Hex. Flanged Screw M6 X 30, Scotch Grip
    Hex. Flanged Screw M6 X 30, Scotch Grip
  • 230
    224061201 Flat Washer
    Flat Washer
  • 250
    705012822 Fascia
    Fascia
  • 260
    715006452 Pure Magnesium, LH Front Fender Kit
    Pure Magnesium, LH Front Fender Kit
  • 270
    715006067 Pure Magnesium Front RH Fender
    Pure Magnesium Front RH Fender
  • 280
    705009253 Black Front Bumper Support
    Black Front Bumper Support
  • 290
    705004565 Lower Fender Support
    Lower Fender Support
  • 300
    715006095 Magnesium Hood
    Magnesium Hood
  • 310
    715002784 Rack Kit
    Rack Kit
  • 320
    705005469 Tube
    Tube
  • 330
    705005470 Tube
    Tube
  • 340
    705004523 Lugage Rack Moulding
    Lugage Rack Moulding
  • 350
    705011553 LH Support Luggage Rack Ass'y. Includes 350 to 350c
    LH Support Luggage Rack Ass'y. Includes 350 to 350c
  • 350a
    269501943 Elastic Nut Housing M8. Includes 350a to 350b
    Elastic Nut Housing M8. Includes 350a to 350b
  • 350b
    232581200 Hex. Elastic Nut M8, Brass
    Hex. Elastic Nut M8, Brass
  • 350c
    232561600 Hex. Elastic Stop Nut M6
    Hex. Elastic Stop Nut M6
  • 360
    705011555 RH Support Luggage Rack Ass'y. Includes 360 to 360c
    RH Support Luggage Rack Ass'y. Includes 360 to 360c
  • 360a
    269501943 Elastic Nut Housing M8. Includes 360a to 360b
    Elastic Nut Housing M8. Includes 360a to 360b
  • 360b
    232581200 Hex. Elastic Nut M8, Brass
    Hex. Elastic Nut M8, Brass
  • 360c
    232561600 Hex. Elastic Stop Nut M6
    Hex. Elastic Stop Nut M6
  • 370
    250000646 Torx Screw M6 X 35
    Torx Screw M6 X 35
  • 375
    293150104 Pop Rivet 3/16''
    Pop Rivet 3/16''
  • 380
    517124300 Washer
    Washer
  • 390
    250100199 Insert Half Hex Body M6 x 1.0
    Insert Half Hex Body M6 x 1.0
  • 395
    207561644 Hex.Fla. Screw M6 X 16, Scotch Grip
    Hex.Fla. Screw M6 X 16, Scotch Grip
  • 405
    241140060 Screw K40 X 10
    Screw K40 X 10
  • 415
    207567044 Hex. Flanged Screw M6x70, Scotch Grip
    Hex. Flanged Screw M6x70, Scotch Grip
  • 420
    250000886 Torx Screw M8 X 30
    Torx Screw M8 X 30
  • 420
    250000886 Torx Screw M8 X 30
    Torx Screw M8 X 30
  • 430
    207683534 Hex. Flanged Screw M8 X 35
    Hex. Flanged Screw M8 X 35
  • 460
    517302785 Edge Clip
    Edge Clip
  • 470
    250000101 Plastite Screw Type K-40, M4 X 25
    Plastite Screw Type K-40, M4 X 25
  • 570
    732610072 Push Nut
    Push Nut
  • 600
    705006300 Front Guard Plate
    Front Guard Plate
  • 610
    205003044 Socket Screw M10 x 30
    Socket Screw M10 x 30
  • 640
    705004497 Ring
    Ring
  • 660
    705011909 Pure Magnesium LH Lateral Pannel
    Pure Magnesium LH Lateral Pannel
  • 670
    705011910 Pure Magnesium RH Lateral Pannel
    Pure Magnesium RH Lateral Pannel
  • 675
    250000723 Phillips Screw K40 X 16
    Phillips Screw K40 X 16
  • 680
    705014060 LH Central Panel
    LH Central Panel
  • 690
    705003444 Engine Cover
    Engine Cover
  • 700
    705012572 Gauge Support. Includes 700 to 700a
    Gauge Support. Includes 700 to 700a
  • 710
    715002783 Dash Kit
    Dash Kit
  • 720
    705003264 Grommet
    Grommet
  • 730
    705013925 RH Wheel Arch Protector
    RH Wheel Arch Protector
  • 740
    705011463 LH Wheel Arch Protector
    LH Wheel Arch Protector
  • 750
    705013924 LH Rear Inner Fender
    LH Rear Inner Fender
  • 760
    705011465 LH Front Inner Fender
    LH Front Inner Fender
  • 770
    293150230 Tuflok Plastic Rivet
    Tuflok Plastic Rivet
  • 780
    293250242 Rubber Cover
    Rubber Cover
  • 1040
    708200408 Box Ass'y. Includes 1040 to 1040b
    Box Ass'y. Includes 1040 to 1040b
  • 1040a
    269501945 Clip. Includes 1040a to 1040b
    Clip. Includes 1040a to 1040b
  • 1040b
    715900411 Neoprene Seal
    Neoprene Seal
