REAR SUSPENSION REAR ARM SHOCK ABSORBER для Arctic Cat ZR 8000 RR ES 137 GREEN INTERNATIONAL - 2018 года выпуска`
-
№АртикулНазвание
-
13704-253 COMPLETE SHOCK ABSORBER (INC. 2-13)COMPLETE SHOCK ABSORBER (INC. 2-13)
-
24604-215 ...SPACER...SPACER
-
34604-216 ...SLEEVE...SLEEVE
-
43603-399 ...BUSHING, EYELET...BUSHING, EYELET
-
52604-223 ...SLEEVE...SLEEVE
-
61604-222 ...BUSHING...BUSHING
-
73603-520 ...KNOB, DAMPING ADJUSTER - REBOUND...KNOB, DAMPING ADJUSTER - REBOUND
-
83603-377 ...SCREW, MACHINE...SCREW, MACHINE
-
93603-418 ...DECAL, WARNING...DECAL, WARNING
-
103603-365 ...DECAL, "PERFORMANCE SERIES"...DECAL, "PERFORMANCE SERIES"
-
113603-437 ...DECAL, RESERVOIR...DECAL, RESERVOIR
-
123603-523 ...DECAL, BASE VALUE...DECAL, BASE VALUE
-
134604-160 ...KIT, SEAL/REBUILD...KIT, SEAL/REBUILD
-
145639-530 OIL, SHOCK - 1 QTOIL, SHOCK - 1 QT
-
158408-045 SCREW, CAPSCREW, CAP
-
162623-202 NUT, LOCK W/WASHERNUT, LOCK W/WASHER
Все узлы модели:
- A-ARM AND SWAY BAR ASSEMBLY
- BATTERY ASSEMBLY
- BELT GUARD ASSEMBLY
- BUMPERS AND STORAGE
- CHAIN CASE ASSEMBLY
- CONSOLE ASSEMBLY
- COOLING ASSEMBLY
- CRANKCASE ASSEMBLY
- CYLINDER AND HEAD ASSEMBLY
- DECALS
- DRIVE CLUTCH
- DRIVE TRAIN SHAFTS AND BRAKE ASSEMBLIES
- DRIVEN CLUTCH
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- FRONT FRAME ASSEMBLY
- FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY
- FUEL PUMP ASSEMBLY
- GAS TANK ASSEMBLY
- HANDLEBAR AND CONTROLS
- HEADLIGHT AND WIRING ASSEMBLIES
- HOOD AND AIR INTAKE ASSEMBLY
- HYDRAULIC BRAKE CONTROL ASSEMBLY
- IDLER WHEEL ASSEMBLY
- MAGNETO
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT
- REAR SUSPENSION FRONT ARM ASSEMBLY
- REAR SUSPENSION FRONT ARM SHOCK ABSORBER
- REAR SUSPENSION REAR ARM ASSEMBLY
- • REAR SUSPENSION REAR ARM SHOCK ABSORBER
- RECOIL STARTER
- REED VALVE ASSEMBLY
- SEAT ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SKID PLATE AND SIDE PANEL ASSEMBLY
- SLIDE RAIL AND TRACK ASSEMBLY
- STARTER MOTOR ASSEMBLY
- STEERING POST ASSEMBLY
- STEERING SUPPORT ASSEMBLY
- THROTTLE BODY ASSEMBLY
- TIE ROD ASSEMBLY
- TUNNEL AND SNOWFLAP ASSEMBLY
- WATER PUMP AND THERMOSTAT
- WINDSHIELD AND INSTRUMENTS ASSEMBLIES
