FRONT SUSPENSION SHOCK ABSORBER ASSEMBLY для Arctic Cat ZR 6000 LTD ES 129 GREEN - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    3703-476 COMPLETE SHOCK ABSORBER (INC. 2-16)
    COMPLETE SHOCK ABSORBER (INC. 2-16)
  • 2
    1604-222 ...BUSHING
    ...BUSHING
  • 3
    2604-223 ...SLEEVE
    ...SLEEVE
  • 4
    3603-283 ...BUSHING
    ...BUSHING
  • 5
    3603-520 ...KNOB, DAMPING ADJUSTER - REBOUND
    ...KNOB, DAMPING ADJUSTER - REBOUND
  • 6
    3603-377 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 7
    4604-016 ...GUIDE, SPRING
    ...GUIDE, SPRING
  • 8
    0403-490 ...RETAINER, SPRING
    ...RETAINER, SPRING
  • 9
    3603-024 ...BUMPER, SHAFT
    ...BUMPER, SHAFT
  • 10
    3603-028 ...WASHER
    ...WASHER
  • 11
    3603-026 ...PRELOAD RING
    ...PRELOAD RING
  • 12
    3603-027 ...PRELOAD RING, BACK-UP
    ...PRELOAD RING, BACK-UP
  • 13
    3603-523 ...DECAL, BASE VALUE
    ...DECAL, BASE VALUE
  • 14
    3603-521 ...DECAL, RESERVOIR
    ...DECAL, RESERVOIR
  • 15
    3603-365 ...DECAL, "PERFORMANCE SERIES"
    ...DECAL, "PERFORMANCE SERIES"
  • 16
    3603-522 ...KIT, SEAL/CAP REBUILD
    ...KIT, SEAL/CAP REBUILD
  • 17
    3703-599 SPRING COMPRESSION - WHITE
    SPRING COMPRESSION - WHITE
  • 18
    3604-109 SLEEVE
    SLEEVE
  • 19
    8408-050 SCREW, CAP
    SCREW, CAP
  • 20
    8427-002 NUT, LOCK
    NUT, LOCK
  • 21
    5639-530 OIL, SHOCK - 1 QT
    OIL, SHOCK - 1 QT
