HOOD AND AIR INTAKE ASSEMBLY для Arctic Cat ZR 6000 EL TIGRE ES 129 GREEN - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    5718-638 HOOD W/DECALS - RIGHT - GREEN (SEE DECALS PAGE FOR DECALS)
    HOOD W/DECALS - RIGHT - GREEN (SEE DECALS PAGE FOR DECALS)
  • 1
    5718-639 HOOD W/DECALS - LEFT - GREEN (SEE DECALS PAGE FOR DECALS)
    HOOD W/DECALS - LEFT - GREEN (SEE DECALS PAGE FOR DECALS)
  • 1
    7606-144 HOOD W/O DECALS - RIGHT - GREEN
    HOOD W/O DECALS - RIGHT - GREEN
  • 1
    7606-145 HOOD W/O DECALS - LEFT - GREEN
    HOOD W/O DECALS - LEFT - GREEN
  • 2
    5718-329 PLENUM, AIR INTAKE - LOWER REAR - W/FOIL (INC. 3)
    PLENUM, AIR INTAKE - LOWER REAR - W/FOIL (INC. 3)
  • 3
    7606-307 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 4
    7606-050 PLENUM, AIR INTAKE - LOWER FRONT
    PLENUM, AIR INTAKE - LOWER FRONT
  • 5
    1623-929 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 6
    8050-217 WASHER
    WASHER
  • 7
    0608-758 SCREEN, INTAKE DUCT - RIGHT
    SCREEN, INTAKE DUCT - RIGHT
  • 7
    0608-759 SCREEN, INTAKE DUCT - LEFT
    SCREEN, INTAKE DUCT - LEFT
  • 8
    0608-748 DUCT, INTAKE - RIGHT
    DUCT, INTAKE - RIGHT
  • 8
    0608-749 DUCT, INTAKE - LEFT
    DUCT, INTAKE - LEFT
  • 9
    5718-328 PLENUM, INTAKE - UPPER (INC. 10)
    PLENUM, INTAKE - UPPER (INC. 10)
  • 10
    0617-648 ...FOAM, INTAKE
    ...FOAM, INTAKE
  • 11
    4411-479 DECAL, AIRCAT
    DECAL, AIRCAT
  • 12
    7606-258 VENT - RIGHT
    VENT - RIGHT
  • 12
    7606-259 VENT - LEFT
    VENT - LEFT
  • 13
    6606-386 SEAL
    SEAL
  • 14
    1623-939 NUT, U
    NUT, U
  • 15
    1623-933 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 16
    7606-056 BEZEL, VENT - RIGHT
    BEZEL, VENT - RIGHT
  • 16
    7606-057 BEZEL, VENT - LEFT
    BEZEL, VENT - LEFT
  • 17
    2623-058 SCREW, SHOULDER
    SCREW, SHOULDER
  • 18
    2623-211 SCREW
    SCREW
  • 19
    2623-004 NUT, PUSH
    NUT, PUSH
  • 20
    2623-003 PIN, RETAINING
    PIN, RETAINING
  • 21
    2623-164 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 22
    2670-444 BOOT
    BOOT
  • 23
    0824-052 SENSOR, T-MAP
    SENSOR, T-MAP
  • 24
    2623-016 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 25
    0423-018 CLAMP, HOSE
    CLAMP, HOSE
  • 26
    0617-624 ADAPTER, BOOT
    ADAPTER, BOOT
  • 27
    1770-056 BOOT, INTAKE
    BOOT, INTAKE
  • 28
    2623-166 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 29
    0621-989 DECAL, REFLECTOR - AMBER
    DECAL, REFLECTOR - AMBER
