WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat M 9000 KING CAT 162 BLACK (USA/INTL) - 2018 года выпуска

  • №
    Артикул
    Название
  • 1
    6706-308 POD, INSTRUMENT - BLACK
    POD, INSTRUMENT - BLACK
  • 2
    2623-166 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 3
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 4
    7606-427 SCREEN, INTAKE - LEFT
    SCREEN, INTAKE - LEFT
  • 5
    7606-426 SCREEN, INTAKE - RIGHT
    SCREEN, INTAKE - RIGHT
  • 6
    0720-041 GAUGE, SPEEDOMETER
    GAUGE, SPEEDOMETER
  • 7
    0609-911 SWITCH, IGNITION (INC. 8-10)
    SWITCH, IGNITION (INC. 8-10)
  • 8
    0430-050 ...NUT, RETAINING
    ...NUT, RETAINING
  • 9
    0430-042 ...KEY, IGNITION - Y SERIES - LEFT-SIDE CUT
    ...KEY, IGNITION - Y SERIES - LEFT-SIDE CUT
  • 9
    0430-043 ...KEY, IGNITION - Z SERIES - RIGHT-SIDE CUT
    ...KEY, IGNITION - Z SERIES - RIGHT-SIDE CUT
  • 10
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 11
    7606-543 BAG, GOGGLE
    BAG, GOGGLE
  • 12
    2623-042 SCREW, SHOULDER
    SCREW, SHOULDER
  • 13
    7606-599 WINDSHIELD - LOW - ORANGE
    WINDSHIELD - LOW - ORANGE
  • 14
    2623-235 RIVET, PLASTIC - REINSTALLABLE
    RIVET, PLASTIC - REINSTALLABLE
