SKID PLATE AND SIDE PANEL ASSEMBLY для Arctic Cat ZR 6000 SNO PRO ES 129 GREEN - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    5718-130 PANEL, SIDE - W/DECALS - RIGHT - BLACK (INC. 2-7, 13-15, 17-20, AND 31)
    PANEL, SIDE - W/DECALS - RIGHT - BLACK (INC. 2-7, 13-15, 17-20, AND 31)
  • 2
    3718-180 PANEL, SIDE - RIGHT W/FOAM - BLACK (INC. 3-7 AND 17-20)
    PANEL, SIDE - RIGHT W/FOAM - BLACK (INC. 3-7 AND 17-20)
  • 3
    0617-626 FOAM, SIDE PANEL - UPPER FRONT - RIGHT
    FOAM, SIDE PANEL - UPPER FRONT - RIGHT
  • 4
    6606-414 FOIL, PROTECTIVE - MIDDLE - SIDE - PANEL
    FOIL, PROTECTIVE - MIDDLE - SIDE - PANEL
  • 5
    0617-628 FOAM, SIDE PANEL - UPPER REAR - RIGHT
    FOAM, SIDE PANEL - UPPER REAR - RIGHT
  • 6
    0617-632 FOAM, SIDE PANEL - LOWER FRONT - RIGHT
    FOAM, SIDE PANEL - LOWER FRONT - RIGHT
  • 7
    0617-634 FOAM, SIDE PANEL - LOWER REAR - RIGHT
    FOAM, SIDE PANEL - LOWER REAR - RIGHT
  • 8
    5718-131 PANEL, SIDE - W/DECALS - LEFT - BLACK (INC. 9-20)
    PANEL, SIDE - W/DECALS - LEFT - BLACK (INC. 9-20)
  • 9
    4718-553 PANEL, SIDE W/FOAM- LEFT - BLACK (INC. 10-12 AND 16-20)
    PANEL, SIDE W/FOAM- LEFT - BLACK (INC. 10-12 AND 16-20)
  • 10
    0617-629 FOAM, SIDE PANEL - UPPER REAR - LEFT
    FOAM, SIDE PANEL - UPPER REAR - LEFT
  • 11
    0617-635 FOAM, SIDE PANEL - LOWER REAR - LEFT
    FOAM, SIDE PANEL - LOWER REAR - LEFT
  • 12
    0617-681 FOAM, SIDE PANEL - LOWER FRONT - LEFT
    FOAM, SIDE PANEL - LOWER FRONT - LEFT
  • 13
    3621-352 DECAL, SIDE PANEL - UPPER - RIGHT - BLACK - "ZR 6000"
    DECAL, SIDE PANEL - UPPER - RIGHT - BLACK - "ZR 6000"
  • 13
    3621-353 DECAL, SIDE PANEL - UPPER - LEFT - BLACK - "ZR 6000"
    DECAL, SIDE PANEL - UPPER - LEFT - BLACK - "ZR 6000"
  • 13
    3621-362 DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK
    DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK
  • 14
    3621-362 DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK
    DECAL, SIDE PANEL - LOWER REAR - RIGHT - BLACK
  • 14
    3621-363 DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK
    DECAL, SIDE PANEL - LOWER REAR - LEFT - BLACK
  • 15
    3621-360 DECAL, SIDE PANEL - FRONT - RIGHT
    DECAL, SIDE PANEL - FRONT - RIGHT
  • 15
    3621-361 DECAL, SIDE PANEL - FRONT - LEFT <TAG NAME="NEW PART" VALUE="X"/>
    DECAL, SIDE PANEL - FRONT - LEFT <TAG NAME="NEW PART" VALUE="X"/>
  • 16
    1623-637 CLIP, U-NUT
    CLIP, U-NUT
  • 17
    0607-447 CABLE
    CABLE
  • 18
    0605-283 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 20
    8050-127 WASHER
    WASHER
  • 21
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 22
    1623-052 CLIP, U-NUT
    CLIP, U-NUT
  • 23
    6606-925 SCREEN, INTAKE
    SCREEN, INTAKE
  • 24
    2602-794 DUCT, INTAKE - INNER
    DUCT, INTAKE - INNER
  • 25
    1623-030 CLIP, U-NUT
    CLIP, U-NUT
  • 26
    2602-793 DUCT, INTAKE - OUTER - BLACK
    DUCT, INTAKE - OUTER - BLACK
  • 27
    0619-206 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 28
    6606-925 SCREEN, INTAKE
    SCREEN, INTAKE
  • 29
    1702-369 DUCT, BELT COOLING
    DUCT, BELT COOLING
  • 30
    6606-694 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 31
    3621-358 DECAL, SIDE PANEL - MID - RIGHT
    DECAL, SIDE PANEL - MID - RIGHT
  • 31
    3621-367 DECAL, SIDE PANEL - VENT - LEFT
    DECAL, SIDE PANEL - VENT - LEFT
  • 32
    5718-140 PLATE, SKID - W/DECALS - RIGHT - BLACK (INC. 33-40 AND 62)
    PLATE, SKID - W/DECALS - RIGHT - BLACK (INC. 33-40 AND 62)
  • 33
    4718-158 PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 34-40)
    PLATE, SKID - RIGHT W/FOAM- BLACK (INC. 34-40)
  • 34
    0617-640 FOAM, SKID PLATE - UPPER REAR - RIGHT
    FOAM, SKID PLATE - UPPER REAR - RIGHT
  • 35
    0617-638 FOAM, SKID PLATE - CENTER FRONT - RIGHT
    FOAM, SKID PLATE - CENTER FRONT - RIGHT
  • 36
    0617-636 FOAM, SKID PLATE - UPPER FRONT - RIGHT
    FOAM, SKID PLATE - UPPER FRONT - RIGHT
  • 37
    2612-970 FOAM, SKID PLATE - UPPER FRONT - RIGHT"
    FOAM, SKID PLATE - UPPER FRONT - RIGHT"
  • 38
    8061-708 RIVET
    RIVET
  • 39
    2612-754 DEFLECTOR, HEAT"
    DEFLECTOR, HEAT"
  • 40
    0123-802 WASHER
    WASHER
  • 41
    5718-137 PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 38, 40, 42-46 AND 62)
    PLATE, SKID - W/DECALS - LEFT - BLACK (INC. 38, 40, 42-46 AND 62)
  • 42
    3718-789 PLATE, SKID - LEFT W/FOAM - BLACK (INC. 38, 40 AND 43-46
    PLATE, SKID - LEFT W/FOAM - BLACK (INC. 38, 40 AND 43-46
  • 43
    0617-637 FOAM, SKID PLATE - UPPER FRONT - LEFT
    FOAM, SKID PLATE - UPPER FRONT - LEFT
  • 44
    0617-639 FOAM, SKID PLATE - CENTER FRONT - LEFT
    FOAM, SKID PLATE - CENTER FRONT - LEFT
  • 45
    0617-641 FOAM, SKID PLATE - UPPER REAR - LEFT
    FOAM, SKID PLATE - UPPER REAR - LEFT
  • 46
    6606-613 PANEL, REINFORCEMENT
    PANEL, REINFORCEMENT
  • 47
    2623-005 CLIP, RETAINING
    CLIP, RETAINING
  • 48
    6606-592 PIN, RETAINING
    PIN, RETAINING
  • 49
    2612-972 PLATE, EXHAUST OUTLET
    PLATE, EXHAUST OUTLET
  • 50
    2612-971 SEAL, EXHAUST OUTLET
    SEAL, EXHAUST OUTLET
  • 51
    1712-963 DEFLECTOR, EXHAUST OUTLET - BLACK
    DEFLECTOR, EXHAUST OUTLET - BLACK
  • 52
    8061-710 RIVET
    RIVET
  • 53
    6606-940 SHIELD, HEAT - ECM
    SHIELD, HEAT - ECM
  • 54
    8408-620 SCREW, CAP
    SCREW, CAP
  • 55
    0730-266 ECM
    ECM
  • 56
    0423-031 CLIP, U-NUT
    CLIP, U-NUT
  • 57
    8060-686 RIVET
    RIVET
  • 58
    6606-342 FASCIA, FRONT - RIGHT - BLACK
    FASCIA, FRONT - RIGHT - BLACK
  • 58
    3718-303 FASCIA, FRONT - LEFT - BLACK (INC. 59)
    FASCIA, FRONT - LEFT - BLACK (INC. 59)
  • 59
    6606-405 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 60
    2623-001 NUT, PUSH
    NUT, PUSH
  • 61
    1623-999 SCREW, THUMB
    SCREW, THUMB
  • 62
    3621-364 DECAL, SKID PLATE - RIGHT
    DECAL, SKID PLATE - RIGHT
  • 62
    3621-365 DECAL, SKID PLATE - LEFT
    DECAL, SKID PLATE - LEFT
