CONSOLE ASSEMBLY для Arctic Cat PANTERA 7000 XT LTD BLACK - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    7606-083 CONSOLE - BLACK
    CONSOLE - BLACK
  • 2
    0641-897 OUTLET, ACCESSORY (12V)
    OUTLET, ACCESSORY (12V)
  • 3
    0609-836 SWITCH, HEATED SEAT
    SWITCH, HEATED SEAT
  • 4
    0609-944 NUT, RETAINING
    NUT, RETAINING
  • 5
    0609-945 COVER, OUTLET - SHIELD
    COVER, OUTLET - SHIELD
  • 6
    0609-940 OUTLET, HEATED SHIELD
    OUTLET, HEATED SHIELD
  • 7
    0430-054 COVER, KEY
    COVER, KEY
  • 8
    0430-042 KEY, IGNITION - Y SERIES (LEFT BLANK)
    KEY, IGNITION - Y SERIES (LEFT BLANK)
  • 8
    0430-043 KEY, IGNITION - Z SERIES (RIGHT BLANK)
    KEY, IGNITION - Z SERIES (RIGHT BLANK)
  • 9
    0430-050 NUT, RETAINING
    NUT, RETAINING
  • 10
    0609-911 SWITCH, IGNITION (INC. 7-9)
    SWITCH, IGNITION (INC. 7-9)
  • 11
    0630-243 ALARM, REVERSE (INC. 12)
    ALARM, REVERSE (INC. 12)
  • 12
    0630-017 ...RING, RETAINING
    ...RING, RETAINING
  • 13
    8061-428 RIVET
    RIVET
  • 14
    6606-926 SHIFT BOOT
    SHIFT BOOT
  • 15
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 16
    6606-989 SUPPORT PLATE - SHIFT BOOT
    SUPPORT PLATE - SHIFT BOOT
  • 17
    6606-852 STRAP, HOLD-DOWN - HOOD
    STRAP, HOLD-DOWN - HOOD
  • 18
    6606-390 NUT, RETAINING
    NUT, RETAINING
