WINDSHIELD AND INSTRUMENTS ASSEMBLIES для Arctic Cat PANTERA 3000 BLACK - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    6606-628 POD, INSTRUMENT - BLACK
    POD, INSTRUMENT - BLACK
  • 2
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 3
    0641-897 OUTLET, ACCESSORY (12V)
    OUTLET, ACCESSORY (12V)
  • 4
    6606-556 VENT, POD
    VENT, POD
  • 5
    0609-911 SWITCH, IGNITION (INC. 6-8)
    SWITCH, IGNITION (INC. 6-8)
  • 6
    0430-050 ...NUT, RETAINING
    ...NUT, RETAINING
  • 7
    0430-042 ...KEY, IGNITION - Y SERIES (LEFT BLANK)
    ...KEY, IGNITION - Y SERIES (LEFT BLANK)
  • 7
    0430-043 ...KEY, IGNITION - Z SERIES (RIGHT BLANK)
    ...KEY, IGNITION - Z SERIES (RIGHT BLANK)
  • 8
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 9
    0720-038 GAUGE, SPEEDOMETER (INC. 10)
    GAUGE, SPEEDOMETER (INC. 10)
  • 10
    0409-161 ...RING, MOUNT - GAUGE
    ...RING, MOUNT - GAUGE
  • 11
    2623-042 SCREW, SHOULDER
    SCREW, SHOULDER
  • 12
    1623-025 INSERT
    INSERT
  • 13
    5706-668 BRACKET, MOUNTING - WINDSHIELD - RIGHT - BLACK
    BRACKET, MOUNTING - WINDSHIELD - RIGHT - BLACK
  • 13
    5706-669 BRACKET, MOUNTING - WINDSHIELD - LEFT - BLACK
    BRACKET, MOUNTING - WINDSHIELD - LEFT - BLACK
  • 14
    8427-502 NUT, LOCK
    NUT, LOCK
  • 15
    2623-017 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 16
    8477-516 SCREW, MACHINE
    SCREW, MACHINE
  • 17
    6606-587 WINDSHIELD - HIGH - TOURING
    WINDSHIELD - HIGH - TOURING
  • 18
    2623-146 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 19
    6639-769 MIRROR KIT (SINGLE) - BLACK (INC. FOUR NO. 14)
    MIRROR KIT (SINGLE) - BLACK (INC. FOUR NO. 14)
  • 19
    6639-770 MIRROR KIT (PAIR) - BLACK (INC. EIGHT NO. 14)
    MIRROR KIT (PAIR) - BLACK (INC. EIGHT NO. 14)
  • 20
    2606-853 RETAINER, WINDSHIELD
    RETAINER, WINDSHIELD
