FRONT FASCIA AND CENTER SKID PLATE ASSEMBLY для Arctic Cat BEARCAT 7000 XT BLUE - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    6606-852 STRAP, HOLD-DOWN - HOOD
    STRAP, HOLD-DOWN - HOOD
  • 2
    0744-088 KIT, TOOL
    KIT, TOOL
  • 3
    2623-166 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 4
    0613-174 BRACKET, MOUNTING - RADIATOR - UPPER
    BRACKET, MOUNTING - RADIATOR - UPPER
  • 5
    6606-884 SKID PLATE - CENTER
    SKID PLATE - CENTER
  • 6
    1623-939 NUT, U
    NUT, U
  • 7
    4718-446 FRONT FASCIA W/REFLECTORS (INC. 8)
    FRONT FASCIA W/REFLECTORS (INC. 8)
  • 8
    1621-390 ...DECAL, REFLECTOR - AMBER - RIGHT
    ...DECAL, REFLECTOR - AMBER - RIGHT
  • 8
    1621-391 ...DECAL, REFLECTOR - AMBER - LEFT
    ...DECAL, REFLECTOR - AMBER - LEFT
  • 9
    1623-030 CLIP, U-NUT
    CLIP, U-NUT
  • 10
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 11
    6606-854 CLOSE-OFF - RIGHT
    CLOSE-OFF - RIGHT
  • 11
    6606-855 CLOSE-OFF - LEFT
    CLOSE-OFF - LEFT
  • 12
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 13
    6606-790 GRILLE, RADIATOR
    GRILLE, RADIATOR
  • 14
    1623-933 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    2621-997 DECAL, HOOD - "C-TEC4"
    DECAL, HOOD - "C-TEC4"
