CARBURETOR AND FUEL PUMP ASSEMBLY для Arctic Cat BEARCAT 2000 XT BLUE INTERNATIONAL - 2017 года выпуска`
-
№АртикулНазвание
-
10623-652 CLAMP, HOSECLAMP, HOSE
-
20610-442 HOSE, DRAIN - 1.5 IN.HOSE, DRAIN - 1.5 IN.
-
30115-544 FLANGE, CARBURETOR (INC. 4-5)FLANGE, CARBURETOR (INC. 4-5)
-
40109-709 ...CLAMP...CLAMP
-
56505-819 ...SCREW...SCREW
-
60670-210 SPACERSPACER
-
70610-415 CLAMP, HOSECLAMP, HOSE
-
80610-772 HOSE, GASLINE - 25 FTHOSE, GASLINE - 25 FT
-
98427-602 NUT, LOCKNUT, LOCK
-
101670-262 PUMP, FUELPUMP, FUEL
-
110619-776 CONDUIT, FLEXIBLE - 5 FTCONDUIT, FLEXIBLE - 5 FT
-
120610-007 HOSE, IMPULSE - 25HOSE, IMPULSE - 25
-
130610-563 CLAMP, HOSECLAMP, HOSE
-
140610-691 HOSE, GASLINE - 10 FTHOSE, GASLINE - 10 FT
-
152670-346 FILTER, FUEL - INLINEFILTER, FUEL - INLINE
Все узлы модели:
- A-ARM ASSEMBLY
- AIR SILENCER ASSEMBLY
- ARTICULATING SKID FRAME ASSEMBLY
- BATTERY AND TRAY ASSEMBLY
- BELT GUARD ASSEMBLY
- CARBURETOR
- • CARBURETOR AND FUEL PUMP ASSEMBLY
- CHASSIS ASSEMBLY
- CONSOLE ASSEMBLY (INTL)
- CRANKCASE AND CYLINDER
- CYLINDER COWLING ASSEMBLY
- DRIVE CLUTCH
- DRIVE TRAIN SHAFT AND BRAKE ASSEMBLIES
- DRIVEN CLUTCH
- ELECTRIC START - STARTER MOTOR ASSEMBLY
- ELECTRICAL
- ENGINE AND RELATED PARTS
- EXHAUST ASSEMBLY
- FRONT SEAT ASSEMBLY
- FRONT SHOCK ABSORBER ASSEMBLY
- GAS TANK ASSEMBLY
- GEARCASE ASSEMBLY
- HANDLEBAR AND CONTROLS
- HEADLIGHT AND WIRING ASSEMBLIES
- HOOD- WINDSHIELD- AND FRONT BUMPER ASSEMBLY
- HYDRAULIC BRAKE CONTROL ASSEMBLY
- IDLER WHEEL ASSEMBLY
- INTAKE ASSEMBLY
- MAGNETO
- OIL PUMP
- OIL TANK ASSEMBLY
- PISTON AND CRANKSHAFT
- REAR BUMPER- RACK RAIL- SNOWFLAP- AND TAILLIGHT ASSEMBLY
- REAR PASSENGER SEAT AND BACKREST ASSEMBLY
- REAR SUSPENSION FRONT ARM ASSEMBLY
- REAR SUSPENSION REAR ARM ASSEMBLY
- RECOIL STARTER
- REED VALVE ASSEMBLY
- SEAT SUPPORT ASSEMBLY
- SKI AND SPINDLE ASSEMBLY
- SKID PLATE AND SIDE PANEL ASSEMBLY
- SLIDE RAIL AND TRACK ASSEMBLY
- STEERING POST ASSEMBLY
- STEERING SUPPORT ASSEMBLY
- TIE ROD ASSEMBLY
