BATTERY ASSEMBLY для Arctic Cat M 8000 SNO PRO 141 ES GREEN INTERNATIONAL [S2016M8HMMOSG] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    0745-406 BATTERY (INC. 2-3)
    BATTERY (INC. 2-3)
  • 2
    0645-430 ...DECAL, WARNING
    ...DECAL, WARNING
  • 3
    0445-082 ...KIT, HARDWARE
    ...KIT, HARDWARE
  • 4
    0645-674 BRACKET, HOLD-DOWN - BATTERY
    BRACKET, HOLD-DOWN - BATTERY
  • 5
    8468-616 SCREW, MACHINE
    SCREW, MACHINE
  • 6
    8427-602 NUT, LOCK
    NUT, LOCK
  • 7
    0645-673 SOLENOID, STARTER RELAY
    SOLENOID, STARTER RELAY
  • 8
    0624-524 NUT W/WASHER
    NUT W/WASHER
  • 9
    0645-648 CABLE, BATTERY/GROUND (INC. 10 AND ONE NO. 11)
    CABLE, BATTERY/GROUND (INC. 10 AND ONE NO. 11)
  • 10
    0645-662 ...BOOT, TERMINAL - BATTERY
    ...BOOT, TERMINAL - BATTERY
  • 11
    0645-697 ...BOOT, TERMINAL - BATTERY
    ...BOOT, TERMINAL - BATTERY
  • 12
    0623-877 NUT W/WASHER
    NUT W/WASHER
  • 13
    0645-650 CABLE, SOLENOID/STARTER (INC. 14 AND ONE NO. 11)
    CABLE, SOLENOID/STARTER (INC. 14 AND ONE NO. 11)
  • 14
    0645-581 ...BOOT, TERMINAL - BATTERY
    ...BOOT, TERMINAL - BATTERY
  • 15
    0645-732 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 16
    8053-242 WASHER, EXTERNAL TOOTH LOCK
    WASHER, EXTERNAL TOOTH LOCK
  • 17
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 17
    0123-903 TIE, CABLE - 11.5 IN.
    TIE, CABLE - 11.5 IN.
  • 18
    0623-144 TIE, CABLE - 17.5 IN.
    TIE, CABLE - 17.5 IN.
