SKI AND SPINDLE ASSEMBLY для Arctic Cat BEARCAT 2000 XT BLUE INTERNATIONAL [S2016BCDWTOSL] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    0623-831 CAP, SPINDLE
    CAP, SPINDLE
  • 2
    2703-372 SPINDLE, STEERING - RIGHT - BLACK (INC. 3-10)
    SPINDLE, STEERING - RIGHT - BLACK (INC. 3-10)
  • 2
    2703-373 SPINDLE, STEERING - LEFT - BLACK (INC. 3-10)
    SPINDLE, STEERING - LEFT - BLACK (INC. 3-10)
  • 3
    0623-796 ...RING, RETAINING
    ...RING, RETAINING
  • 4
    4706-116 ...ARM, SPINDLE - RIGHT HAND - PLATINUM
    ...ARM, SPINDLE - RIGHT HAND - PLATINUM
  • 4
    4706-117 ...ARM, SPINDLE - LEFT HAND - PLATINUM
    ...ARM, SPINDLE - LEFT HAND - PLATINUM
  • 5
    0623-872 ...SCREW, CAP
    ...SCREW, CAP
  • 6
    2603-382 ...WASHER, THRUST
    ...WASHER, THRUST
  • 7
    1623-654 ...FITTING, GREASE - 1/4-28 STR-THREAD FORMING
    ...FITTING, GREASE - 1/4-28 STR-THREAD FORMING
  • 8
    1603-895 ...BEARING
    ...BEARING
  • 9
    1623-582 ...SCREW, CAP
    ...SCREW, CAP
  • 10
    0603-158 ...BEARING
    ...BEARING
  • 11
    2603-730 AXLE, SPINDLE
    AXLE, SPINDLE
  • 12
    2603-731 SPACER
    SPACER
  • 13
    0603-036 DAMPER, SKI
    DAMPER, SKI
  • 14
    2603-729 SKI, PLASTIC - BLACK
    SKI, PLASTIC - BLACK
  • 15
    2603-746 INSERT
    INSERT
  • 16
    2603-950 HANDLE, PLASTIC - BLACK
    HANDLE, PLASTIC - BLACK
  • 17
    8427-602 NUT, LOCK
    NUT, LOCK
  • 18
    8476-650 SCREW, MACHINE
    SCREW, MACHINE
  • 19
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 20
    0703-871 WEARBAR
    WEARBAR
  • 21
    8047-486 NUT, LOCK
    NUT, LOCK
  • 22
    0423-744 NUT, LOCK
    NUT, LOCK
  • 23
    8050-282 WASHER
    WASHER
  • 24
    0123-458 PIN, COTTER
    PIN, COTTER
  • 25
    1623-718 BOLT, SKI-HFH M 10 - 1.25 X 200 CL10.9
    BOLT, SKI-HFH M 10 - 1.25 X 200 CL10.9
