CONSOLE ASSEMBLY для Arctic Cat BEARCAT 2000 XT (RUSSIAN) (BLUE) [S2015BCDWTRUL] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    4706-836 HOUSING, SPEEDOMETER/TACHOMETER
    HOUSING, SPEEDOMETER/TACHOMETER
  • 2
    0620-364 SPEEDOMETER/TACHOMETER
    SPEEDOMETER/TACHOMETER
  • 3
    0620-322 BRACKET, RETAINING
    BRACKET, RETAINING
  • 4
    0423-493 NUT W/WASHER
    NUT W/WASHER
  • 5
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 6
    1623-618 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 7
    4718-554 CONSOLE - BLACK (INC. 8-10)
    CONSOLE - BLACK (INC. 8-10)
  • 8
    2621-286 ...DECAL, WARNING - RUSSIAN
    ...DECAL, WARNING - RUSSIAN
  • 9
    2621-287 ...DECAL, CAUTION - RUSSIAN
    ...DECAL, CAUTION - RUSSIAN
  • 10
    1411-798 ...DECAL, STEERING WHEEL
    ...DECAL, STEERING WHEEL
  • 11
    0617-558 FOAM, CONSOLE - FRONT
    FOAM, CONSOLE - FRONT
  • 12
    0617-559 FOAM, CONSOLE - REAR
    FOAM, CONSOLE - REAR
  • 13
    0623-785 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 14
    1623-669 SCREW, SHOULDER - TSTRH M6 X 1.0 X 80MM
    SCREW, SHOULDER - TSTRH M6 X 1.0 X 80MM
  • 15
    5606-658 CLOSE-OFF, HANDLEBAR
    CLOSE-OFF, HANDLEBAR
  • 16
    6606-011 NUT, RETAINING
    NUT, RETAINING
  • 17
    0687-208 CABLE, CHOKE (INC. 18)
    CABLE, CHOKE (INC. 18)
  • 18
    0687-219 ...KIT,CHOKE LEVER- 08 570
    ...KIT,CHOKE LEVER- 08 570
  • 19
    0609-910 SWITCH, IGNITION (INC. 20-22)
    SWITCH, IGNITION (INC. 20-22)
  • 20
    0430-054 ...COVER, KEY
    ...COVER, KEY
  • 21
    0430-042 ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
    ...KEY, IGNITION - (Y SERIES - LEFT-SIDE CUT)
  • 21
    0430-043 ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
    ...KEY, IGNITION - (Z SERIES - RIGHT-SIDE CUT)
  • 22
    0430-050 ...NUT, FLANGE - IGNITION SWITCH
    ...NUT, FLANGE - IGNITION SWITCH
  • 23
    0630-264 WASHER
    WASHER
