HOOD AND AIR INTAKE ASSEMBLY для Arctic Cat ZR 8000 Sno Pro RR NE OS - GREEN - INTERNTIONAL [S2014ZRHNEOSG] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    3718-920 HOOD W/DECALS - RIGHT - GREEN (INC. 2-3 AND 5-6)
    HOOD W/DECALS - RIGHT - GREEN (INC. 2-3 AND 5-6)
  • 1
    3718-921 HOOD W/DECALS - LEFT - GREEN (INC. 2-6)
    HOOD W/DECALS - LEFT - GREEN (INC. 2-6)
  • 2
    3718-656 ...HOOD W/O DECALS - RIGHT - GREEN (INC. 3)
    ...HOOD W/O DECALS - RIGHT - GREEN (INC. 3)
  • 2
    3718-657 ...HOOD W/O DECALS - LEFT - GREEN (INC. 3-4)
    ...HOOD W/O DECALS - LEFT - GREEN (INC. 3-4)
  • 3
    0617-646 ......FOAM, HOOD - RIGHT
    ......FOAM, HOOD - RIGHT
  • 3
    0617-647 ......FOAM, HOOD - LEFT
    ......FOAM, HOOD - LEFT
  • 4
    6606-407 ......FOIL, PROTECTIVE
    ......FOIL, PROTECTIVE
  • 5
    0621-664 ...DECAL, HOOD - UPPER RIGHT
    ...DECAL, HOOD - UPPER RIGHT
  • 5
    0621-665 ...DECAL, HOOD - UPPER LEFT
    ...DECAL, HOOD - UPPER LEFT
  • 6
    0621-784 ...DECAL, HOOD - FORWARD RIGHT
    ...DECAL, HOOD - FORWARD RIGHT
  • 6
    0621-785 ...DECAL, HOOD - FORWARD LEFT
    ...DECAL, HOOD - FORWARD LEFT
  • 7
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 8
    1623-960 O-RING
    O-RING
  • 9
    5706-356 PLENUM, INTAKE - UPPER (INC. 10)
    PLENUM, INTAKE - UPPER (INC. 10)
  • 10
    0617-648 ...FOAM, INTAKE
    ...FOAM, INTAKE
  • 11
    9611-752 DECAL, "ARCTIC CAT"
    DECAL, "ARCTIC CAT"
  • 12
    6606-386 BOOT, INTAKE
    BOOT, INTAKE
  • 13
    0623-165 CLIP, RETAINING
    CLIP, RETAINING
  • 14
    1623-933 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 15
    0623-797 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 16
    1623-939 CLIP, U-NUT
    CLIP, U-NUT
  • 17
    1623-929 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 18
    5706-358 PLENUM, INTAKE - LOWER REAR (INC. 19)
    PLENUM, INTAKE - LOWER REAR (INC. 19)
  • 19
    6606-406 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 20
    6606-822 RETAINER, PLENUM
    RETAINER, PLENUM
  • 21
    5706-357 PLENUM, INTAKE - LOWER FRONT (INC. 22)
    PLENUM, INTAKE - LOWER FRONT (INC. 22)
  • 22
    0621-989 ...DECAL, REFLECTOR - AMBER
    ...DECAL, REFLECTOR - AMBER
  • 23
    0617-624 ADAPTER, BOOT
    ADAPTER, BOOT
  • 24
    2670-328 BOOT
    BOOT
  • 25
    0423-018 CLAMP
    CLAMP
