REAR BUMPER- RACK RAIL- SNOWFLAP- AND TAILLIGHT ASSEMBLY для Arctic Cat Bearcat 570 XT - ORANGE [S2014BCDWTUSO] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    5706-065 RISER, SEAT - ASSEMBLY
    RISER, SEAT - ASSEMBLY
  • 2
    1623-345 STUD, SEAT
    STUD, SEAT
  • 3
    1623-083 NUT
    NUT
  • 4
    8422-002 NUT, LOCK
    NUT, LOCK
  • 5
    0123-802 WASHER
    WASHER
  • 6
    8060-706 RIVET
    RIVET
  • 7
    4606-162 CABLE
    CABLE
  • 8
    1623-022 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 9
    8408-616 SCREW, CAP
    SCREW, CAP
  • 10
    1623-984 CLAMP, ROUTING
    CLAMP, ROUTING
  • 11
    4706-072 KIT, TOOL
    KIT, TOOL
  • 12
    0623-579 HINGE, SEAT-BASE
    HINGE, SEAT-BASE
  • 13
    5606-802 SEAL,SEAT BASE (13 1/2")-RISER
    SEAL,SEAT BASE (13 1/2")-RISER
  • 14
    5606-803 SEAL,SEAT BASE (16")-RISER
    SEAL,SEAT BASE (16")-RISER
  • 15
    0621-585 DECAL, RISER - ORANGE
    DECAL, RISER - ORANGE
  • 16
    0441-592 INSERT
    INSERT
  • 17
    8476-820 SCREW, MACHINE
    SCREW, MACHINE
  • 18
    4706-258 MOUNT, RACK - RIGHT
    MOUNT, RACK - RIGHT
  • 18
    4706-259 MOUNT, RACK - LEFT
    MOUNT, RACK - LEFT
  • 19
    8427-802 NUT, LOCK
    NUT, LOCK
  • 20
    1623-782 SCREW, MACHINE
    SCREW, MACHINE
  • 21
    0623-184 WASHER, FLAT 1/4 X 1.0 Z & Y
    WASHER, FLAT 1/4 X 1.0 Z & Y
  • 22
    3606-740 SNOWFLAP
    SNOWFLAP
  • 23
    8427-602 NUT, LOCK
    NUT, LOCK
  • 24
    8476-835 SCREW, MACHINE
    SCREW, MACHINE
  • 25
    2707-008 BUMPER, REAR - ORANGE
    BUMPER, REAR - ORANGE
  • 26
    5611-852 DECAL, WARNING - TOWING - ENGLISH
    DECAL, WARNING - TOWING - ENGLISH
  • 27
    5611-853 DECAL, WARNING - TOWING - FRENCH
    DECAL, WARNING - TOWING - FRENCH
  • 28
    4606-156 HITCH, PINTLE
    HITCH, PINTLE
  • 29
    8050-242 WASHER, FLAT- 5/16 X .625 X .063 Z & Y
    WASHER, FLAT- 5/16 X .625 X .063 Z & Y
  • 30
    8408-832 SCREW, CAP
    SCREW, CAP
  • 31
    0609-887 TAILLIGHT, LED
    TAILLIGHT, LED
  • 32
    1623-786 CLAMP, WIRE
    CLAMP, WIRE
  • 33
    0623-301 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
