REAR SUSPENSION REAR ARM ASSEMBLY для Arctic Cat M 1100 Turbo - 153 - BLACK [S2013M1NE3USB] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    8408-826 SCREW, CAP
    SCREW, CAP
  • 2
    3604-673 AXLE
    AXLE
  • 3
    2704-083 ARM, REAR - GREEN (INC. ONE NO. 4)
    ARM, REAR - GREEN (INC. ONE NO. 4)
  • 4
    1623-010 ...FITTING, GREASE
    ...FITTING, GREASE
  • 5
    8408-031 SCREW, CAP
    SCREW, CAP
  • 6
    3604-638 AXLE
    AXLE
  • 7
    2704-081 ARM, IDLER - GREEN (INC. TWO NO. 4 AND 8-10)
    ARM, IDLER - GREEN (INC. TWO NO. 4 AND 8-10)
  • 8
    3604-028 ...BUSHING, FLARED
    ...BUSHING, FLARED
  • 9
    1623-011 ...WASHER
    ...WASHER
  • 10
    2604-852 ...BUSHING
    ...BUSHING
  • 11
    3604-636 AXLE, INNER CARRIAGE
    AXLE, INNER CARRIAGE
  • 12
    1623-692 WASHER, WAVE
    WASHER, WAVE
  • 13
    2604-699 WHEEL, IDLER (INC. 14-15)
    WHEEL, IDLER (INC. 14-15)
  • 14
    0107-598 ...BEARING
    ...BEARING
  • 15
    0123-798 ...RING, RETAINING
    ...RING, RETAINING
  • 16
    1623-690 RING, RETAINING
    RING, RETAINING
  • 17
    1623-836 SCREW, CAP
    SCREW, CAP
  • 18
    1704-683 LINK, REAR SHOCK - GREEN
    LINK, REAR SHOCK - GREEN
  • 19
    8408-045 SCREW, CAP
    SCREW, CAP
  • 20
    3604-109 SLEEVE
    SLEEVE
  • 21
    8427-002 NUT, LOCK
    NUT, LOCK
  • 22
    2703-905 SPRING - GREEN
    SPRING - GREEN
  • 23
    3604-200 RETAINER, SPRING
    RETAINER, SPRING
  • 24
    2704-190 SHOCK ABSORBER
    SHOCK ABSORBER
