CONSOLE AND SWITCH ASSEMBLY для Arctic Cat SNO PRO 600 CROSS COUNTRY - 2012 года выпуска

  • №
    Артикул
    Название
  • 1
    6606-425 CONSOLE, UPPER - BLACK
    CONSOLE, UPPER - BLACK
  • 2
    0609-904 SWITCH, HANDWARMER/THUMBWARMER (INC. 3)
    SWITCH, HANDWARMER/THUMBWARMER (INC. 3)
  • 3
    0609-905 ...NUT
    ...NUT
  • 4
    9611-053 DECAL, SWITCH - HANDWARMER/THUMBWARMER
    DECAL, SWITCH - HANDWARMER/THUMBWARMER
  • 5
    1623-748 CLIP, RETAINING
    CLIP, RETAINING
  • 6
    0423-538 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 7
    0687-228 CABLE, CHOKE (INC. 8)
    CABLE, CHOKE (INC. 8)
  • 8
    0687-181 ...NUT
    ...NUT
  • 9
    0709-071 TETHER SWITCH (INC. 10-11)
    TETHER SWITCH (INC. 10-11)
  • 10
    0709-055 ...TETHER CORD W/SCREW (INC. 11)
    ...TETHER CORD W/SCREW (INC. 11)
  • 11
    0623-338 ......SCREW, SELF-TAPPING
    ......SCREW, SELF-TAPPING
  • 12
    0123-985 WASHER, INTERNAL TOOTH LOCK
    WASHER, INTERNAL TOOTH LOCK
