DRIVE TRAIN SHAFT AND BRAKE ASSEMBLIES для Arctic Cat Z1 TURBO SNO PRO (ORANGE) - 2011 года выпуска`

№

Артикул

Название
1

1602-957 NUT, RETAINING

NUT, RETAINING

1 870 ₽
2

1623-461 SCREW, CAP-HFH-7/16-14X1 3/4 GR8 W/2353

SCREW, CAP-HFH-7/16-14X1 3/4 GR8 W/2353

3 110 ₽
3

1602-656 DISC, BRAKE

DISC, BRAKE

39 930 ₽
4

1602-480 SPACER, BRAKE CALIPER

SPACER, BRAKE CALIPER

7 900 ₽
5

2602-076 SHIELD, BEARING

SHIELD, BEARING

1 870 ₽
6

0728-181 TRACK, DRIVE - ASSEMBLY (INC. 7-8)

TRACK, DRIVE - ASSEMBLY (INC. 7-8)

68 220 ₽
7

0702-880 ...SHAFT, DRIVE W/RETAINER-ASSY

...SHAFT, DRIVE W/RETAINER-ASSY

62 190 ₽
8

1602-783 ...SPROCKET, DRIVE-10T-45MM HEX

...SPROCKET, DRIVE-10T-45MM HEX

9 980 ₽
9

1602-984 SEAL

SEAL

2 070 ₽
10

1702-060 PLATE, MOUNTING - REVERSE

PLATE, MOUNTING - REVERSE

8 110 ₽
11

1623-355 NUT, PUSH

NUT, PUSH

380 ₽
12

1702-167 GEARCASE ASSEMBLY

GEARCASE ASSEMBLY

420 ₽
13

8427-802 NUT, LOCK

NUT, LOCK

90 ₽
14

8476-830 SCREW, MACHINE

SCREW, MACHINE

1 450 ₽
15

0708-487 BRACKET, RUBBER SNUBBER

BRACKET, RUBBER SNUBBER

4 150 ₽
16

0608-595 SNUBBER, RUBBER

SNUBBER, RUBBER

690 ₽
17

0648-442 WASHER, SHIM (.030 IN.)

WASHER, SHIM (.030 IN.)

1 660 ₽
17

0648-443 WASHER, SHIM (.060 IN.)

WASHER, SHIM (.060 IN.)

210 ₽
18

4606-939 SHIELD, ACTUATOR

SHIELD, ACTUATOR

3 110 ₽
19

0706-371 TRIM, RACK-36

TRIM, RACK-36

3 110 ₽
20

0726-306 CLUTCH, DRIVEN-10.4 (46/38 ORN) W/PLATES

CLUTCH, DRIVEN-10.4 (46/38 ORN) W/PLATES

109 820 ₽
21

0648-441 O-RING

O-RING

90 ₽
22

0648-714 WASHER, SHIM (.090 IN.)

WASHER, SHIM (.090 IN.)

310 ₽
22

0648-715 WASHER, SHIM (.030 IN.)

WASHER, SHIM (.030 IN.)

190 ₽
22

0648-716 WASHER, SHIM (.060 IN.)

WASHER, SHIM (.060 IN.)

520 ₽
23

1702-114 ADJUSTER, SHEAVE (INC. 24)

ADJUSTER, SHEAVE (INC. 24)

4 780 ₽
24

0648-788 ...WASHER, THRUST

...WASHER, THRUST

290 ₽
25

1623-415 WASHER, FLAT-.875X.400X.156 Z & Y

WASHER, FLAT-.875X.400X.156 Z & Y

1 240 ₽
26

8051-272 WASHER, SPR LOCK-3/8 .377X.680X.094 Z & Y

WASHER, SPR LOCK-3/8 .377X.680X.094 Z & Y

20 ₽
27

1623-572 SCREW, CAP-HFH 3/8-16X4.50 GR8-VENTED

SCREW, CAP-HFH 3/8-16X4.50 GR8-VENTED

4 990 ₽
28

8477-845 SCREW, MACH-TSTRH M8X1.25X45 Z & BLK

SCREW, MACH-TSTRH M8X1.25X45 Z & BLK

520 ₽
29

1702-018 CALIPER, BRAKE - ASSEMBLY (INC. 30-45)

CALIPER, BRAKE - ASSEMBLY (INC. 30-45)

111 480 ₽
30

1623-713 ...BOLT, CARRIAGE - RIBBED

...BOLT, CARRIAGE - RIBBED

3 740 ₽
31

1602-458 ...FITTING, BLEED

...FITTING, BLEED

650 ₽
32

1602-461 ...PISTON, STAINLESS-1.93X.79

...PISTON, STAINLESS-1.93X.79

12 890 ₽
33

1602-669 ...O-RING

...O-RING

3 110 ₽
34

0702-563 ...PAD, BRAKE - SET (INC. 35-36)

...PAD, BRAKE - SET (INC. 35-36)

17 470 ₽
35

1602-466 ...CLIP, ANTI-RATTLE

...CLIP, ANTI-RATTLE

1 450 ₽
36

1602-467 ...CLIP, HAIRPIN

...CLIP, HAIRPIN

920 ₽
37

1602-464 ...PIN, RETAINING - BRAKE PAD

...PIN, RETAINING - BRAKE PAD

920 ₽
38

0602-729 ...O-RING, HOUSING

...O-RING, HOUSING

860 ₽
39

2602-132 ...SPACER, SPEEDOMETER BRACKET

...SPACER, SPEEDOMETER BRACKET

2 490 ₽
40

0402-165 ...WASHER

...WASHER

460 ₽
41

1602-670 ...BOLT, SHCS 5/16-18 UNC-2A 3.00 LG

...BOLT, SHCS 5/16-18 UNC-2A 3.00 LG

480 ₽
42

1602-671 ...BOLT, SHCS 5/16-18 UNC-2A 2.00 LG

...BOLT, SHCS 5/16-18 UNC-2A 2.00 LG

770 ₽
43

2602-131 ...BEARING, 45MM X 68MM X 12MM

...BEARING, 45MM X 68MM X 12MM

8 520 ₽
44

1602-463 ...SLEEVE, DRIVESHAFT

...SLEEVE, DRIVESHAFT

4 780 ₽
45

1602-456 ...RING, RETAINING

...RING, RETAINING

4 150 ₽
46

1602-978 FITTING, INLET

FITTING, INLET

3 320 ₽
47

6606-167 PLATE, MOUNTING - SPEEDOMETER SENSOR

PLATE, MOUNTING - SPEEDOMETER SENSOR

1 870 ₽
48

0430-091 SENSOR, SPEEDOMETER

SENSOR, SPEEDOMETER

7 270 ₽
49

8468-617 SCREW, MACH-TSPNH M6X1.0X16 CL8.8 W/2353

SCREW, MACH-TSPNH M6X1.0X16 CL8.8 W/2353

190 ₽
