FUEL PUMP ASSEMBLY для Arctic Cat Z1 TURBO LXR (GREEN) - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-898 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 2
    2670-042 PLATE, RETAINING - FUEL PUMP
    PLATE, RETAINING - FUEL PUMP
  • 3
    2670-052 PUMP, FUEL - ASSEMBLY (INC. 4)
    PUMP, FUEL - ASSEMBLY (INC. 4)
  • 4
    2670-235 ...FLOAT
    ...FLOAT
  • 5
    0470-838 SEAL
    SEAL
  • 6
    2670-053 PICKUP, FUEL - ASSEMBLY (INC. 7 AND ONE NO. 8)
    PICKUP, FUEL - ASSEMBLY (INC. 7 AND ONE NO. 8)
  • 7
    0610-691 ...HOSE, GASLINE - 10 FT
    ...HOSE, GASLINE - 10 FT
  • 8
    0610-563 ...CLAMP, HOSE
    ...CLAMP, HOSE
  • 9
    1670-878 FITTING, QUICK-CONNECT
    FITTING, QUICK-CONNECT
  • 10
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 10
    0623-751 TIE, CABLE - 11.75 IN.
    TIE, CABLE - 11.75 IN.
  • 11
    1619-349 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
  • 12
    1670-825 FILTER, FUEL
    FILTER, FUEL
  • 13
    0410-143 HOSE, GASLINE - 25 FT
    HOSE, GASLINE - 25 FT
  • 14
    2670-137 FITTING, ELBOW
    FITTING, ELBOW
  • 15
    0610-419 CLAMP, HOSE
    CLAMP, HOSE
  • 16
    1619-359 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
