IDLER WHEEL ASSEMBLY для Arctic Cat CFR 1000 - 2010 года выпуска`
-
№АртикулНазвание
-
18020-134 SCREW, CAPSCREW, CAP
-
28020-142 SCREW, CAPSCREW, CAP
-
33604-004 BLOCK, MOUNTING - IDLER WHEELBLOCK, MOUNTING - IDLER WHEEL
-
43604-486 WHEEL, IDLERWHEEL, IDLER
-
58047-426 NUT, LOCKNUT, LOCK
-
68450-133 WASHERWASHER
-
71623-037 SCREW, CAPSCREW, CAP
-
80623-439 WASHERWASHER
-
93604-083 SPACER, SHOCK - FRONT ARMSPACER, SHOCK - FRONT ARM
-
100623-912 WASHERWASHER
-
113604-080 AXLEAXLE
-
128047-490 NUT, LOCKNUT, LOCK
-
130704-994 PIVOT, REAR SHOCK (INC. 14-16)PIVOT, REAR SHOCK (INC. 14-16)
-
141623-011 ...WASHER...WASHER
-
151623-010 ...FITTING, GREASE...FITTING, GREASE
-
160603-083 ...BEARING...BEARING
-
171604-209 AXLEAXLE
-
182604-109 SPACERSPACER
-
198047-486 NUT, LOCKNUT, LOCK
-
202604-378 BLOCK, SLIDEBLOCK, SLIDE
-
212604-515 SLIDE, SPRINGSLIDE, SPRING
-
228050-282 WASHERWASHER
-
238020-229 SCREW, CAPSCREW, CAP
-
242604-890 SPACERSPACER
-
258051-277 WASHER, LOCKWASHER, LOCK
-
268042-486 NUTNUT
-
271623-354 SCREW, CAPSCREW, CAP
-
281604-810 SPACER, REAR WHEELSPACER, REAR WHEEL
-
292604-874 AXLE, REARAXLE, REAR
-
303604-060 WHEEL, IDLER (INC. 31-32)WHEEL, IDLER (INC. 31-32)
-
313604-033 ...BEARING...BEARING
-
320623-946 ...RING, RETAINING...RING, RETAINING
-
332604-881 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
341704-490 BUSHING, ADJUSTERBUSHING, ADJUSTER
-
353604-066 WHEEL, IDLER - GREEN (INC. 31-32)WHEEL, IDLER - GREEN (INC. 31-32)
-
360623-664 WASHERWASHER
-
371623-248 SCREW, CAPSCREW, CAP
-
381604-952 CAP, IDLER WHEELCAP, IDLER WHEEL
