DRIVE CLUTCH для Arctic Cat M8 EFI 162'' (BLACK) - 2008 года выпуска

  • №
    Артикул
    Название
  • 0746-192 UNCALIBRATED DRIVE CLUTCH
    UNCALIBRATED DRIVE CLUTCH
  • 4639-674 CAM ARM KIT (INC. 5-8)
    CAM ARM KIT (INC. 5-8)
  • 1
    1623-442 SCREW, MACHINE
    SCREW, MACHINE
  • 2
    8051-212 WASHER, LOCK - SPRING
    WASHER, LOCK - SPRING
  • 3
    0646-229 SPRING, DRIVE CLUTCH - YELLOW/WHITE
    SPRING, DRIVE CLUTCH - YELLOW/WHITE
  • 4
    0746-716 ARM, CAM (INC. 5)
    ARM, CAM (INC. 5)
  • 4
    0746-715 ARM, CAM (INC. 5) (0-3,000 FT ALT.)
    ARM, CAM (INC. 5) (0-3,000 FT ALT.)
  • 4
    0746-672 ARM, CAM (INC. 5) (3-6,000 FT ALT.)
    ARM, CAM (INC. 5) (3-6,000 FT ALT.)
  • 4
    0746-703 ARM, CAM (INC. 5) (OVER 9,000 FT ALT.)
    ARM, CAM (INC. 5) (OVER 9,000 FT ALT.)
  • 5
    1623-183 ...SCREW, SET
    ...SCREW, SET
  • 6
    1602-692 O-RING
    O-RING
  • 7
    0646-747 PIN, CAM ARM
    PIN, CAM ARM
  • 8
    8048-366 NUT, LOCK
    NUT, LOCK
