STEERING POST ASSEMBLY для Arctic Cat F8 EFI (BLACK) - 2008 года выпуска`
-
№АртикулНазвание
-
10623-872 SCREW, CAPSCREW, CAP
-
20705-355 CAP, ADJUSTING BLOCK - UPPERCAP, ADJUSTING BLOCK - UPPER
-
30605-884 RISER, HANDLEBARRISER, HANDLEBAR
-
40605-676 CAP, ADJUSTING BLOCK - LOWERCAP, ADJUSTING BLOCK - LOWER
-
58403-830 SCREW, CAPSCREW, CAP
-
61705-250 POST, STEERINGPOST, STEERING
-
78050-282 WASHERWASHER
-
88427-002 NUT, LOCKNUT, LOCK
-
91705-087 BRACKET, BEARINGBRACKET, BEARING
-
101705-201 PLATE, BEARING BRACKETPLATE, BEARING BRACKET
-
118408-617 SCREW, CAPSCREW, CAP
