FRONT SUSPENSION SHOCK ABSORBER для Arctic Cat CROSSFIRE 800 EFI - 2008 года выпуска`
-
№АртикулНазвание
-
2703-008 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
12603-262 BODY, SHOCKBODY, SHOCK
-
21603-501 EYELET, SHOCKEYELET, SHOCK
-
32603-461 ROD, SHOCKROD, SHOCK
-
40603-991 BUMPER, SHOCKBUMPER, SHOCK
-
51703-452 CAP, SHOCK (INC. 6)CAP, SHOCK (INC. 6)
-
61604-271 ...O-RING...O-RING
-
71604-272 WASHER, TOP OUTWASHER, TOP OUT
-
82603-055 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
92603-065 VALVE, 0.900 X 0.010 IN.VALVE, 0.900 X 0.010 IN.
-
102603-075 VALVE, 1.000 X 0.010 IN.VALVE, 1.000 X 0.010 IN.
-
112603-095 VALVE, 1.100 X 0.010 IN.VALVE, 1.100 X 0.010 IN.
-
122603-124 VALVE, 1.250 X 0.008 IN.VALVE, 1.250 X 0.008 IN.
-
132603-047 VALVE, 0.700 X 0.015 IN.VALVE, 0.700 X 0.015 IN.
-
142603-052 VALVE, 0.800 X 0.006 IN.VALVE, 0.800 X 0.006 IN.
-
152603-132 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
161603-996 PISTON, 0.120 IN. - ORIFICEPISTON, 0.120 IN. - ORIFICE
-
171604-274 STRAP, PISTON - TEFLONSTRAP, PISTON - TEFLON
-
182603-125 VALVE, 1.250 X 0.010 IN.VALVE, 1.250 X 0.010 IN.
-
190623-696 NUT, LOCKNUT, LOCK
-
200704-791 PISTON, FLOATING (INC. 21-22)PISTON, FLOATING (INC. 21-22)
-
212604-152 ...O-RING...O-RING
-
222604-153 ...STRAP, PISTON - TEFLON...STRAP, PISTON - TEFLON
-
232603-012 SLEEVE, PROTECTORSLEEVE, PROTECTOR
-
241603-911 NUT, ADJUSTERNUT, ADJUSTER
-
251603-209 SLEEVE, EYELETSLEEVE, EYELET
-
261603-914 BUSHING, SHOCKBUSHING, SHOCK
-
270624-433 SCREW, VALVESCREW, VALVE
-
282604-649 VALVE, PRESSURE (INC. 29)VALVE, PRESSURE (INC. 29)
-
292604-162 ...O-RING, VALVE...O-RING, VALVE
-
300603-955 BUSHING, SHOCKBUSHING, SHOCK
-
314639-366 OIL, GAS SHOCK - 1 QTOIL, GAS SHOCK - 1 QT
