GAS TANK- SEAT- AND TAILLIGHT ASSEMBLY для Arctic Cat T660 TURBO TRAIL (GREEN LE) - 2007 года выпуска`
-
№АртикулНазвание
-
12718-044 COMPLETE SEAT ASSEMBLY (INC. 2-19) (LE)COMPLETE SEAT ASSEMBLY (INC. 2-19) (LE)
-
20770-740 ...TANK, GAS/SEAT-BASE (INC. 3-8)...TANK, GAS/SEAT-BASE (INC. 3-8)
-
30670-243 ......PLUG, TANK......PLUG, TANK
-
40670-289 ......TAPE, TEFLON......TAPE, TEFLON
-
51670-494 ......VENT, TANK......VENT, TANK
-
61670-325 ......GROMMET, TANK......GROMMET, TANK
-
71670-199 ......CAP, GAS TANK (INC. 8)......CAP, GAS TANK (INC. 8)
-
81670-228 .........SEAL, GAS TANK CAP.........SEAL, GAS TANK CAP
-
93706-405 ...COVER, SEAT (INC. 10) (LE)...COVER, SEAT (INC. 10) (LE)
-
103606-363 ......WIRE, SEAT......WIRE, SEAT
-
111606-126 ...INSERT, SEAT FOAM...INSERT, SEAT FOAM
-
121606-518 ...INSERT, SEAT PAD - RIGHT...INSERT, SEAT PAD - RIGHT
-
121606-519 ...INSERT, SEAT PAD - LEFT...INSERT, SEAT PAD - LEFT
-
130623-783 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
140624-528 ...STAPLE, SEAT COVER...STAPLE, SEAT COVER
-
153706-310 ...FOAM, SEAT CUSHION...FOAM, SEAT CUSHION
-
162606-943 ...WIRE, SEAT...WIRE, SEAT
-
178050-217 ...WASHER...WASHER
-
180623-309 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
190609-786 ...PAD, SEAT HEATER (LE)...PAD, SEAT HEATER (LE)
-
208020-041 SCREW, CAPSCREW, CAP
-
218047-366 NUT, LOCKNUT, LOCK
-
220623-184 WASHERWASHER
-
230623-404 CAP, PROTECTORCAP, PROTECTOR
-
240609-091 TAILLIGHT W/SOCKET ASSEMBLYTAILLIGHT W/SOCKET ASSEMBLY
-
250109-460 BULBBULB
-
260609-092 GASKET, TAILLIGHT LENSGASKET, TAILLIGHT LENS
-
270609-090 LENS, TAILLIGHTLENS, TAILLIGHT
-
280609-093 SCREW, RETAININGSCREW, RETAINING
-
290623-038 NUT, LOCKNUT, LOCK
-
303002-964 CLAMP, WIRECLAMP, WIRE
-
310617-136 SEAL, FOAM - SEAT-BASESEAL, FOAM - SEAT-BASE
-
326101-001 HOSE, VENT - 100 FTHOSE, VENT - 100 FT
-
326101-009 HOSE, VENT - 50 FTHOSE, VENT - 50 FT
-
331623-042 CLAMP, HOSECLAMP, HOSE
-
340623-101 CLIP, ROUTING - SNAP-INCLIP, ROUTING - SNAP-IN
