HOOD AND WINDSHIELD ASSEMBLY для Arctic Cat T660 TURBO TRAIL (BLACK) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-017 HOOD W/DECALS - BLACK (INC. 2-17, FOURTEEN NO. 18, 19-24, TWELVE NO. 25, AND 26)
    HOOD W/DECALS - BLACK (INC. 2-17, FOURTEEN NO. 18, 19-24, TWELVE NO. 25, AND 26)
  • 2
    1718-931 ...HOOD W/O DECALS - BLACK (INC. 3-17 AND FOURTEEN NO. 18)
    ...HOOD W/O DECALS - BLACK (INC. 3-17 AND FOURTEEN NO. 18)
  • 3
    0717-183 ......FOAM, HOOD - MIDDLE
    ......FOAM, HOOD - MIDDLE
  • 4
    0717-186 ......FOAM, HOOD - GAUGE - RIGHT
    ......FOAM, HOOD - GAUGE - RIGHT
  • 4
    0717-187 ......FOAM, HOOD - GAUGE - LEFT
    ......FOAM, HOOD - GAUGE - LEFT
  • 5
    0717-190 ......FOAM, HOOD - UPPER RIGHT
    ......FOAM, HOOD - UPPER RIGHT
  • 5
    0717-191 ......FOAM, HOOD - UPPER LEFT
    ......FOAM, HOOD - UPPER LEFT
  • 6
    0717-184 ......FOAM, HOOD - FRONT - RIGHT
    ......FOAM, HOOD - FRONT - RIGHT
  • 6
    0717-185 ......FOAM, HOOD - FRONT - LEFT
    ......FOAM, HOOD - FRONT - LEFT
  • 7
    3606-375 ......FOIL, HOOD - SIDE
    ......FOIL, HOOD - SIDE
  • 8
    3606-372 ......FOIL, HOOD - UPPER RIGHT
    ......FOIL, HOOD - UPPER RIGHT
  • 8
    3606-373 ......FOIL, HOOD - UPPER LEFT
    ......FOIL, HOOD - UPPER LEFT
  • 9
    0619-206 ......TAPE, FOIL
    ......TAPE, FOIL
  • 10
    3606-374 ......FOIL, HOOD - LOWER RIGHT
    ......FOIL, HOOD - LOWER RIGHT
  • 11
    3606-376 ......FOIL, HOOD - UPPER
    ......FOIL, HOOD - UPPER
  • 12
    5611-837 ......DECAL, WARNING - BREAK-IN
    ......DECAL, WARNING - BREAK-IN
  • 13
    5611-838 ......DECAL, WARNING (ENGLISH)
    ......DECAL, WARNING (ENGLISH)
  • 13
    5611-839 ......DECAL, WARNING (FRENCH)
    ......DECAL, WARNING (FRENCH)
  • 14
    5611-836 ......DECAL, REVERSE
    ......DECAL, REVERSE
  • 15
    3606-236 ......SCREEN, HOOD - REAR - RIGHT - BLACK
    ......SCREEN, HOOD - REAR - RIGHT - BLACK
  • 15
    3606-237 ......SCREEN, HOOD - REAR - LEFT - BLACK
    ......SCREEN, HOOD - REAR - LEFT - BLACK
  • 16
    4606-161 ......SCREEN, HOOD - MIDDLE - BLACK
    ......SCREEN, HOOD - MIDDLE - BLACK
  • 17
    3606-235 ......SCREEN, HOOD - FRONT - LEFT - BLACK
    ......SCREEN, HOOD - FRONT - LEFT - BLACK
  • 18
    0123-987 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 19
    6611-805 ...EMBLEM, CHROME - HOOD
    ...EMBLEM, CHROME - HOOD
  • 20
    7611-492 ...DECAL, HOOD - LOWER RIGHT
    ...DECAL, HOOD - LOWER RIGHT
  • 20
    7611-493 ...DECAL, HOOD - LOWER LEFT
    ...DECAL, HOOD - LOWER LEFT
  • 21
    7611-490 ...DECAL, HOOD - FRONT - RIGHT
    ...DECAL, HOOD - FRONT - RIGHT
  • 21
    7611-491 ...DECAL, HOOD - FRONT - LEFT
    ...DECAL, HOOD - FRONT - LEFT
  • 22
    2718-016 ...COVER, HOOD W/DECALS - BLACK (INC. 23-24)
    ...COVER, HOOD W/DECALS - BLACK (INC. 23-24)
  • 23
    3606-253 ......COVER, HOOD W/O DECALS - BLACK
    ......COVER, HOOD W/O DECALS - BLACK
  • 24
    7611-489 ......DECAL, HOOD COVER - CREST
    ......DECAL, HOOD COVER - CREST
  • 25
    0616-032 ...O-RING
    ...O-RING
  • 26
    0619-898 ...TAPE, FOAM - 1 FT
    ...TAPE, FOAM - 1 FT
  • 27
    3606-234 SCREEN, HOOD - FRONT - RIGHT - BLACK
    SCREEN, HOOD - FRONT - RIGHT - BLACK
  • 28
    1670-550 DEFLECTOR, AIR INTAKE
    DEFLECTOR, AIR INTAKE
  • 29
    0717-192 FOAM, HOOD - UPPER MIDDLE
    FOAM, HOOD - UPPER MIDDLE
  • 30
    1606-067 STRAP, HOLD-DOWN
    STRAP, HOLD-DOWN
  • 31
    2639-477 MIRROR - KIT - BLACK (INC. SIX NO. 32-34)
    MIRROR - KIT - BLACK (INC. SIX NO. 32-34)
  • 32
    0623-845 ...NUT, EXPANSION
    ...NUT, EXPANSION
  • 33
    0124-054 ...SNAP CAP W/WASHER
    ...SNAP CAP W/WASHER
  • 34
    0623-902 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 35
    3606-408 WINDSHIELD
    WINDSHIELD
  • 36
    2606-247 CABLE, HOOD
    CABLE, HOOD
  • 37
    0623-805 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 38
    1623-164 SCREW, SHOULDER
    SCREW, SHOULDER
