CONSOLE ASSEMBLY для Arctic Cat F5 EFI LXR (ORANGE) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-031 HOUSING, SPEEDOMETER/TACHOMETER (INC. 2)
    HOUSING, SPEEDOMETER/TACHOMETER (INC. 2)
  • 2
    7611-572 ...DECAL, WARNING - HANDLEBAR RISER
    ...DECAL, WARNING - HANDLEBAR RISER
  • 3
    0620-305 SPEEDOMETER/TACHOMETER (INC. 4-5)
    SPEEDOMETER/TACHOMETER (INC. 4-5)
  • 4
    0620-281 ...BRACKET, RETAINING
    ...BRACKET, RETAINING
  • 5
    0620-280 ...NUT W/WASHER
    ...NUT W/WASHER
  • 6
    1623-129 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 7
    1623-661 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 8
    2718-063 CONSOLE - GREEN (INC. 9-12) (GREEN)
    CONSOLE - GREEN (INC. 9-12) (GREEN)
  • 8
    2718-065 CONSOLE - BLACK (INC. 9-12) (BLACK)
    CONSOLE - BLACK (INC. 9-12) (BLACK)
  • 8
    2718-066 CONSOLE - ORANGE (INC. 9-12) (ORANGE)
    CONSOLE - ORANGE (INC. 9-12) (ORANGE)
  • 9
    7611-575 ...DECAL, CAUTION - ENGLISH
    ...DECAL, CAUTION - ENGLISH
  • 10
    7611-574 ...DECAL, CAUTION - FRENCH
    ...DECAL, CAUTION - FRENCH
  • 11
    7611-427 ...DECAL, WARNING - ENGLISH
    ...DECAL, WARNING - ENGLISH
  • 12
    7611-428 ...DECAL, WARNING - FRENCH
    ...DECAL, WARNING - FRENCH
  • 13
    0619-946 FOAM, TAPE - 1 FT
    FOAM, TAPE - 1 FT
  • 14
    0617-522 FOAM, CONSOLE
    FOAM, CONSOLE
  • 15
    1623-592 SCREW, MACHINE
    SCREW, MACHINE
  • 16
    1623-591 SPACER
    SPACER
  • 17
    0641-897 OUTLET, ACCESSORY - 12V
    OUTLET, ACCESSORY - 12V
  • 18
    1623-618 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 19
    0623-785 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 20
    3706-012 CLOSE-OFF, HANDLEBAR
    CLOSE-OFF, HANDLEBAR
  • 21
    0423-396 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 22
    0609-806 SWITCH, IGNITION (INC. 23)
    SWITCH, IGNITION (INC. 23)
  • 24
    0609-113 NUT
    NUT
  • 25
    0123-899 WASHER
    WASHER
  • 26
    0609-450 SPACER
    SPACER
  • 27
    4606-274 GROMMET
    GROMMET
