ENGINE AND RELATED PARTS для Arctic Cat CROSSFIRE 800 EFI (GREEN) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    0662-495 ENGINE, AB80L1 W/O EFI COMPONENTS
    ENGINE, AB80L1 W/O EFI COMPONENTS
  • 2
    0636-363 HANDLE, RECOIL
    HANDLE, RECOIL
  • 3
    0606-885 CAP, RECOIL HANDLE
    CAP, RECOIL HANDLE
  • 4
    8020-136 SCREW, CAP
    SCREW, CAP
  • 5
    0708-471 MOUNT, ENGINE - MAG
    MOUNT, ENGINE - MAG
  • 6
    8047-426 NUT, LOCK
    NUT, LOCK
  • 7
    1623-504 SCREW, CAP
    SCREW, CAP
  • 8
    4606-425 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 9
    0619-619 CONDUIT, FLEXIBLE - 4 IN.
    CONDUIT, FLEXIBLE - 4 IN.
  • 10
    0619-994 CONDUIT, FLEXIBLE (3/4 IN. ID) - 6 IN.
    CONDUIT, FLEXIBLE (3/4 IN. ID) - 6 IN.
  • 11
    0623-373 CLAMP, HOSE
    CLAMP, HOSE
  • 12
    0610-726 HOSE, COOLANT - MAG/THROTTLE BODY
    HOSE, COOLANT - MAG/THROTTLE BODY
  • 13
    0610-699 HOSE, COOLANT - PTO/THROTTLE BODY
    HOSE, COOLANT - PTO/THROTTLE BODY
  • 14
    0619-776 CONDUIT, FLEXIBLE - 5 FT
    CONDUIT, FLEXIBLE - 5 FT
  • 15
    0708-523 BRACKET, ENGINE MOUNTING - ASSEMBLY (INC. ONE NO. 4, ONE NO. 6, AND 16-17)
    BRACKET, ENGINE MOUNTING - ASSEMBLY (INC. ONE NO. 4, ONE NO. 6, AND 16-17)
  • 16
    0708-519 ...BRACKET, ENGINE MOUNTING - FRONT - LOWER RIGHT
    ...BRACKET, ENGINE MOUNTING - FRONT - LOWER RIGHT
  • 17
    0608-549 ...BRACKET, ENGINE MOUNTING - UPPER RIGHT
    ...BRACKET, ENGINE MOUNTING - UPPER RIGHT
  • 18
    0608-467 CAP, MOUNTING BRACKET - ENGINE
    CAP, MOUNTING BRACKET - ENGINE
  • 19
    1623-603 SCREW, CAP
    SCREW, CAP
  • 20
    0708-497 BRACKET, ENGINE MOUNTING - LEFT (INC. 21-22)
    BRACKET, ENGINE MOUNTING - LEFT (INC. 21-22)
  • 21
    8060-730 ...RIVET
    ...RIVET
  • 22
    0608-565 ...PLATE, BACKING - TORQUE BUMPER
    ...PLATE, BACKING - TORQUE BUMPER
  • 23
    0608-462 BUMPER, TORQUE
    BUMPER, TORQUE
  • 24
    0623-987 WASHER
    WASHER
  • 25
    8050-252 WASHER
    WASHER
  • 26
    8413-826 SCREW, CAP
    SCREW, CAP
  • 27
    0746-192 CLUTCH, DRIVE - UNCALIBRATED
    CLUTCH, DRIVE - UNCALIBRATED
  • 28
    0627-046 BELT, DRIVE
    BELT, DRIVE
  • 29
    0623-210 WASHER, HIGH COLLAR
    WASHER, HIGH COLLAR
  • 30
    0623-804 BOLT, CLUTCH
    BOLT, CLUTCH
  • 31
    0623-677 CABLE TIE, PUSH-MOUNT
    CABLE TIE, PUSH-MOUNT
  • 32
    0623-144 CABLE TIE, 17.5 IN.
    CABLE TIE, 17.5 IN.
  • 33
    1623-659 CLAMP, PUSH-MOUNT
    CLAMP, PUSH-MOUNT
