GAS TANK- SEAT- AND TAILLIGHT ASSEMBLY для Arctic Cat AC 120 (ORANGE) - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    2718-040 COMPLETE SEAT ASSEMBLY (INC. 2-9) (GREEN)
    COMPLETE SEAT ASSEMBLY (INC. 2-9) (GREEN)
  • 1
    2718-041 COMPLETE SEAT ASSEMBLY (INC. 2-9) (ORANGE)
    COMPLETE SEAT ASSEMBLY (INC. 2-9) (ORANGE)
  • 2
    2606-844 ...TANK, GAS/SEAT-BASE
    ...TANK, GAS/SEAT-BASE
  • 3
    1670-694 ...CAP, GAS TANK W/GAUGE (INC. 4)
    ...CAP, GAS TANK W/GAUGE (INC. 4)
  • 4
    0109-733 ......SEAL, TANK CAP
    ......SEAL, TANK CAP
  • 5
    3706-520 ...COVER, SEAT (INC. 6) (GREEN)
    ...COVER, SEAT (INC. 6) (GREEN)
  • 5
    3706-374 ...COVER, SEAT (INC. 6) (ORANGE)
    ...COVER, SEAT (INC. 6) (ORANGE)
  • 6
    2606-031 ......WIRE, SEAT
    ......WIRE, SEAT
  • 7
    1706-017 ...FOAM, SEAT
    ...FOAM, SEAT
  • 8
    2606-942 ...WIRE, SEAT
    ...WIRE, SEAT
  • 9
    0624-528 ...STAPLE, SEAT COVER
    ...STAPLE, SEAT COVER
  • 10
    0676-017 VALVE, SHUT-OFF - GAS TANK
    VALVE, SHUT-OFF - GAS TANK
  • 11
    0670-289 TAPE, TEFLON
    TAPE, TEFLON
  • 12
    1623-351 CLAMP, HOSE
    CLAMP, HOSE
  • 13
    6101-001 HOSE, GASLINE/VENT - 100 FT
    HOSE, GASLINE/VENT - 100 FT
  • 13
    6101-009 HOSE, GASLINE/VENT - 50 FT
    HOSE, GASLINE/VENT - 50 FT
  • 14
    1623-042 CLAMP, HOSE
    CLAMP, HOSE
  • 15
    0510-335 FILTER, FUEL
    FILTER, FUEL
  • 16
    3611-856 DECAL, SHUT-OFF VALVE
    DECAL, SHUT-OFF VALVE
  • 17
    0123-579 NUT, PUSH
    NUT, PUSH
  • 18
    0116-469 BUSHING, RECOIL STARTER
    BUSHING, RECOIL STARTER
  • 19
    1670-647 HOSE, VENT
    HOSE, VENT
  • 20
    0123-394 CLIP, CABLE
    CLIP, CABLE
  • 21
    0123-788 CABLE TIE - 7 IN.
    CABLE TIE - 7 IN.
  • 22
    0687-154 CABLE, CHOKE (INC. 23)
    CABLE, CHOKE (INC. 23)
  • 23
    0687-181 ...NUT, CHOKE CABLE
    ...NUT, CHOKE CABLE
  • 24
    0109-822 SWITCH, IGNITION (INC. 25-26)
    SWITCH, IGNITION (INC. 25-26)
  • 25
    0116-065 ...KEY
    ...KEY
  • 26
    0609-111 ...NUT, RETAINING
    ...NUT, RETAINING
  • 27
    4611-767 DECAL, SWITCH/CHOKE
    DECAL, SWITCH/CHOKE
  • 28
    8002-040 SCREW, CAP
    SCREW, CAP
  • 29
    8040-366 NUT, LOCK
    NUT, LOCK
  • 30
    0623-184 WASHER
    WASHER
  • 31
    0123-108 NUT, NYLON CAP
    NUT, NYLON CAP
  • 32
    0609-070 TAILLIGHT ASSEMBLY (INC. 33)
    TAILLIGHT ASSEMBLY (INC. 33)
  • 33
    0230-020 ...BULB, TAILLIGHT
    ...BULB, TAILLIGHT
  • 34
    8050-157 WASHER
    WASHER
  • 35
    0123-709 NUT W/LOCK WASHER
    NUT W/LOCK WASHER
  • 36
    1623-233 CLAMP, HOSE
    CLAMP, HOSE
