HOOD AND WINDSHIELD ASSEMBLY для Arctic Cat T660 Turbo ST (GREEN) - 2006 года выпуска

  • №
    Артикул
    Название
  • 1
    1718-813 HOOD W/DECALS (INC. 2, 27 AND TWELVE NO. 28)
    HOOD W/DECALS (INC. 2, 27 AND TWELVE NO. 28)
  • 2
    1718-930 HOOD W/O DECALS (INC. 3, 20)
    HOOD W/O DECALS (INC. 3, 20)
  • 3
    0717-192 FOAM, HOOD (UPPER/MIDDLE)
    FOAM, HOOD (UPPER/MIDDLE)
  • 4
    0717-186 FOAM, HOOD, GAUGE (RIGHT)
    FOAM, HOOD, GAUGE (RIGHT)
  • 4
    0717-187 FOAM, HOOD, GAUGE (LEFT)
    FOAM, HOOD, GAUGE (LEFT)
  • 5
    0717-190 FOAM, HOOD (UPPER/RIGHT)
    FOAM, HOOD (UPPER/RIGHT)
  • 5
    0717-191 FOAM, HOOD (UPPER/LEFT)
    FOAM, HOOD (UPPER/LEFT)
  • 6
    0717-188 FOAM, HOOD (REAR/RIGHT)
    FOAM, HOOD (REAR/RIGHT)
  • 6
    0717-189 FOAM, HOOD (REAR/LEFT)
    FOAM, HOOD (REAR/LEFT)
  • 7
    0717-184 FOAM, HOOD (FRONT/RIGHT)
    FOAM, HOOD (FRONT/RIGHT)
  • 7
    0717-185 FOAM, HOOD (FRONT/LEFT)
    FOAM, HOOD (FRONT/LEFT)
  • 8
    0717-183 FOAM, HOOD (MIDDLE)
    FOAM, HOOD (MIDDLE)
  • 9
    3606-376 FOIL, HOOD (CENTER)
    FOIL, HOOD (CENTER)
  • 10
    3606-372 FOIL, HOOD (UPPER/RIGHT)
    FOIL, HOOD (UPPER/RIGHT)
  • 10
    3606-373 FOIL, HOOD (UPPER/LEFT)
    FOIL, HOOD (UPPER/LEFT)
  • 11
    3606-374 FOIL, HOOD (LOWER/RIGHT)
    FOIL, HOOD (LOWER/RIGHT)
  • 12
    3606-375 FOIL, HOOD, SIDE
    FOIL, HOOD, SIDE
  • 13
    2606-556 FOIL, PROTECTIVE, 3 IN. X 6 IN.
    FOIL, PROTECTIVE, 3 IN. X 6 IN.
  • 14
    5611-838 DECAL, WARNING (ENGLISH)
    DECAL, WARNING (ENGLISH)
  • 14
    5611-839 DECAL, WARNING (FRENCH)
    DECAL, WARNING (FRENCH)
  • 15
    5611-836 DECAL, REVERSE
    DECAL, REVERSE
  • 16
    5611-837 DECAL, WARNING, BREAK, INNER
    DECAL, WARNING, BREAK, INNER
  • 17
    3606-236 SCREEN, HOOD (REAR/RIGHT)
    SCREEN, HOOD (REAR/RIGHT)
  • 17
    3606-237 SCREEN, HOOD (REAR/LEFT)
    SCREEN, HOOD (REAR/LEFT)
  • 18
    4606-161 SCREEN, HOOD (MIDDLE)
    SCREEN, HOOD (MIDDLE)
  • 19
    3606-235 SCREEN, HOOD (FRONT/LEFT)
    SCREEN, HOOD (FRONT/LEFT)
  • 20
    0123-987 CLIP, RETAINING
    CLIP, RETAINING
  • 21
    6611-778 DECAL, HOOD (LOWER/RIGHT)
    DECAL, HOOD (LOWER/RIGHT)
  • 21
    6611-779 DECAL, HOOD (LOWER/LEFT)
    DECAL, HOOD (LOWER/LEFT)
  • 22
    6611-776 DECAL, HOOD (FORWARD/RIGHT)
    DECAL, HOOD (FORWARD/RIGHT)
  • 22
    6611-777 DECAL, HOOD (FORWARD/LEFT)
    DECAL, HOOD (FORWARD/LEFT)
  • 23
    1718-815 COVER, HOOD W/DECALS (INC. 24, 25)
    COVER, HOOD W/DECALS (INC. 24, 25)
  • 24
    3606-973 COVER, HOOD W/O DECALS
    COVER, HOOD W/O DECALS
  • 25
    6611-784 DECAL, HOOD, CREST
    DECAL, HOOD, CREST
  • 26
    6611-785 DECAL, "INTERCOOLER"
    DECAL, "INTERCOOLER"
  • 27
    0619-946 TAPE, FOAM, 1 FT
    TAPE, FOAM, 1 FT
  • 28
    0616-032 O-RING
    O-RING
  • 29
    0124-054 SNAP CAP W/WASHER
    SNAP CAP W/WASHER
  • 30
    0623-902 SCREW, MACHINE
    SCREW, MACHINE
  • 31
    0623-845 NUT, EXPANSION
    NUT, EXPANSION
  • 32
    3606-969 WINDSHIELD
    WINDSHIELD
  • 33
    2606-247 CABLE, HOOD
    CABLE, HOOD
  • 34
    0623-805 CLIP, HAIRPIN
    CLIP, HAIRPIN
  • 35
    1606-067 STRAP, HOLD, DOWN
    STRAP, HOLD, DOWN
  • 36
    1623-164 SCREW, SHOULDER
    SCREW, SHOULDER
  • 37
    1670-550 DEFLECTOR, AIR INTAKE
    DEFLECTOR, AIR INTAKE
  • 38
    3606-234 SCREEN, HOOD (FRONT/RIGHT)
    SCREEN, HOOD (FRONT/RIGHT)
  • 39
    0619-206 TAPE, FOIL
    TAPE, FOIL
