SEAT ASSEMBLY для Arctic Cat Crossfire 600 EFI (BLACK) - 2006 года выпуска

  • №
    Артикул
    Название
  • 1
    7998-752 COMPLETE SEAT ASSY (INC. 2, 6)
    COMPLETE SEAT ASSY (INC. 2, 6)
  • 2
    3706-119 COVER, SEAT
    COVER, SEAT
  • 3
    0624-528 STAPLE, SEAT COVER
    STAPLE, SEAT COVER
  • 4
    3706-118 FOAM, SEAT CUSHION
    FOAM, SEAT CUSHION
  • 5
    4606-128 SEAT, BASE
    SEAT, BASE
  • 6
    1623-393 CLIP, RETAINING, SEAT, BASE
    CLIP, RETAINING, SEAT, BASE
  • 7
    1623-458 STUD, LATCH, SEAT, BASE
    STUD, LATCH, SEAT, BASE
  • 8
    8047-426 NUT, LOCK
    NUT, LOCK
  • 9
    0123-788 CABLE TIE, 8 IN.
    CABLE TIE, 8 IN.
  • 10
    0617-512 FOAM, COMPARTMENT, SEAT
    FOAM, COMPARTMENT, SEAT
  • 11
    4606-322 COVER, LATCH, SEAT (RIGHT)
    COVER, LATCH, SEAT (RIGHT)
  • 12
    8061-628 RIVET
    RIVET
